The Table Editor
AWG710&AWG710B Arbitrary Waveform Generator User Manual 3-107
To look at the waveform area outside the current display area, scroll the display
using the general purpose knob or the y and b buttons. If the data to view is more
than 50 data points away from the current cursor location, it is faster to use the
numeric keypad to enter the new cursor value in the Cursor Position field.
Pushing the TOGGLE front–panel button switches the table contents to show the
data values at the other cursor. When toggling between the cursors, the Table Editor
displays the Upper cursor at the top of the table and the Lower cursor at the bottom
of the table.
NOTE. Remember that you need to define the edit area (data points located
between the cursors) before executing the Operation commands.
