Tutorials
2-80 AWG710&AWG710B Arbitrary Waveform Generator User Manual
Figure 2-49: Example of sequence (MAINSEQ.seq)
23. Save the sequence table in the file MAINSEQ.seq. Refer to Save the Sequence
on page 2-76.
Set Run Mode
The event jump functions in the sequence list are only functional when the
instrument run mode is set to Enhanced mode. Do the following steps to set the run
mode to enhanced:
1. Push the SETUP button on the front–panel to display the SETUP screen.
2. Push the Run Mode bottom button.
3. Push the Enhanced side button.
