2-74 AWG710&AWG710B Arbitrary Waveform Generator User Manual
In the sequence file used as subsequence, the Wait Trigger, Goto <N> and Logic
Jump are neglected. They are effective only in the main sequence.
Do the following steps to create the subsequence:
1. Push the Data Entry bottom button.
2. Push the Insert Line side button.
This displays the line number in the Line column and allows you to edit the
line.
3. Push the Enter Filename... side button.
The dialog box listing files appears at the center of the screen.
4. Select GAUSSN.wfm from the dialog box using the general purpose knob.
5. Push the OK side button.
The waveform file name GAUSSN.wfm appears in the CH1 column.
6. Push the b button once to move the highlighted cursor to the next line.
7. Repeat steps 2 through 6 to insert lines 2 through 4 and enter waveform file
names listed in Table 2-17 into the CH1 column.
8. Repeatedly push the y button to go back to Line 1.
9. Push the ' button to place the highlighted cursor on the Repeat Count column.
The side menu automatically changes and the Repeat Count side menu item
appears. Note that the Repeat Count side menu item is selected by default.
10. Push the 4, 0, 0, 0, 0, and ENTER buttons in this order.
The repeat count 40000 is set in the Repeat Count column.
11. Push the b button once to move the highlighted cursor to the next line.
Table 2-17: Sequence table contents in SUBSEQ.seq
Line CH1 Repeat
Count
Wait
Trigg er
Goto
<N>
Logic
Jump
1 GAUSSN.wfm 40,000
2 RAMP.wfm 60,000
3 TRIANGLE.wfm 60,000
4 SINE.wfm 30,000
