Data Sheet

TEK.COM 7
2230G-30-3, 2230G-30-6, 2230G-60-3
High Power, 3-Channel Programmable Power Supplies
General Specifications
Communications USB: Type A to B connector, USB 2.0, USBTMC compatible
GPIB: IEEE Std 488.2 compliant
RS232: Baud Rates: 4800/9600/19,200/38,400/57,600/115,200
Rear-Panel Connectors Output: 15-pin terminal block socket
RS-232: DB-9 connector
USB Device: Type B connector
GPIB: IEEE-compliant 24-pin connector
AC Power Input: 3-prong socket assembly with fuse
Display Vacuum fluorescent display
Memory 36 setup memories
Output and Remote Sense Removable 15-15-pin screw-terminal block carries the following signals:
Output Channels: Duplicates the front-panel outputs
Remote Sense Lines: Connections for remote sense for each channel
Control Input: Multifunction TTL input, which can function as a trigger input, output control line, or
digital input
Status Output: Multifunction TTL output, which can function as a fault indication or digital output
Floating Voltage Rating Up to 400 V (DC + peak AC) between protective earth (safety ground) and any output terminal
Power Source 110 V AC Setting: 99 V
RMS
to 132 V
RMS
108 V
RMS
to 132 V
RMS
(2230G-30-6 and 2230G-60-3 with 2230G-HRM installed)
220 V AC Setting: 198 V
RMS
to 264 V
RMS
Frequency: 50/60 Hz
Power Consumption: 2230G-30-3: 700 VAC; 2230G-30-6, 2230G-60-3: 1000 VAC
EMC European Union: Conforms to European Union EMC directive
USA: FCC, CFR Title 47, Part 15, Subpart B, Class A
Australia: EMC Framework, demonstrated per Emission Standard AS/NZS 2064 (industrial, scientific, and
medical equipment)
Safety European Union: Conforms to Low Voltage Directive
USA: NRTL listed to UL61010-1-2004
Canada: CAN/CSA C22.2 No. 61010-1 2004
Dimensions With boot: 104.2 mm high × 225.3 mm wide × 481.1 mm deep (4.10 in. × 8.87 in. × 18.94 in.)
Without boot: 88.2 mm high × 214.5 mm wide × 456.6 mm deep (3.47 in. × 8.44 in. × 17.98 in.)
Shipping Weight 2230G-30-3: 12.3 kg (27 lb.)
2230G-30-6, 2230G-60-3: 13.8 kg (30 lb.)
Net Weight 2230G-30-3: 9.6 kg (21 lb.)
2230G-30-6, 2230G-60-3: 11.1 kg (24 lb.)
Environment Altitude:
Operating: Up to 2000 meters (6562 ft ) above sea level
Storage: Up to 4000 meters (13124 ft ) above sea level
Operating: 0 °C to 40 °C, 10% to 80% relative humidity up to 40°C
Storage:
–20°C to 70°C, 10% to 80% relative humidity up to 40°C
–20°C to 70°C, 5% to 60% relative humidity above 40°C up to 70°C
