Datasheet
TEK.COM6
2230G-30-3 2230G-30-6 2230G-60-3
CH 1 and CH 2 CH 3 CH 1 and CH 2 CH 3 CH 1 and CH 2 CH 3
Series Setting Resolution
Voltage 1 mV — 1 mV — — —
Current 1 mA — 1 mA — — —
Series Readback Resolution
Voltage 1 mV — 1 mV — — —
Current 1 mA — 1 mA — — —
Parallel Setting Resolution
Voltage 1 mV — 1 mV — 1 mV —
Current 1 mA —
0–9.999A: 1 mA
10–12A: 10 mA
— 1 mA —
Parallel Readback Resolution
Voltage 1 mV — 1 mV — 1 mV —
Current 1 mA —
0–9.999A: 1 mA
10–12A: 10 mA
— 1 mA —
Rise Time (10% to 90%) ≤100 ms ≤100 ms ≤100 ms
Fall Time (90% to 10%) ≤0.5 s ≤0.1 s ≤0.5 s ≤0.1 s ≤1.5 s ≤0.1 s
Load Transient Recovery Time
Voltage setting band 50 mV, 50% to 100%, 1 kKHz, rise and fall rate 5 A per µs: ≤50 µs (typical)
Transition Time
CC mode to CV mode, V-set = 5 V, I-limit = 0.5 A, resistive load change from 2.5 Ω to 25 Ω: ≤10 ms
CV mode to CC mode, V-set = 5 V, I-limit = 0.5 A, resistive load change from 25 Ω to 2.5 Ω: ≤5 ms
Output Timer
Setting Range 0.1 s to 99999.9 s 0.1 s to 99999.9 s 0.1 s to 99999.9 s
Resolution 0.1 s 0.1 s 0.1 s
