TEK.COM 5
2230G-30-3, 2230G-30-6, 2230G-60-3
High Power, 3-Channel Programmable Power Supplies
Specification Conditions
Specifications are the standards against which the 2230G-30-3, 2230G-30-6, and 2230G-60-3 are tested. Upon leaving
the factory, the 2230G-30-3, 2230G-30-6, and 2230G-60-3 meet these specifications. Typical values are not warranted,
apply at 23°C ± 5°C, and are provided solely as useful information. Specifications apply under these conditions:
• Temperature 0°C to 40°C and relative humidity 10% to 80% unless defined differently in this document.
• After a 30-minute warmup period.
• Within one year of the calibration period.
Model-Specific Specifications
2230G-30-3 2230G-30-6 2230G-60-3
CH 1 and CH 2 CH 3 CH 1 and CH 2 CH 3 CH 1 and CH 2 CH 3
DC Output Rating
Voltage 0 V to 30 V 0 V to 5 V 0 V to 30 V 0 V to 5 V 0 V to 60 V 0 V to 5 V
Voltage Limit 30.1 V 5.1 V 30.1 V 5.1 V 60.1 V 5.1 V
Current 0 A to 3 A 0 A to 3 A 0 A to 6 A 0 A to 3 A 0 A to 3 A 0 A to 3 A
Maximum power 195 W 375 W 375 W
Load Regulation
Voltage ≤0.01% + 3 mV ≤0.01% + 3 mV ≤0.01% + 3 mV
Current ≤0.01% + 3 mA ≤0.01% + 3 mA ≤0.01% + 3 mA
Line Regulation
Voltage ≤0.01% + 3 mV ≤0.01% + 3 mV ≤0.01% + 3 mV
Current ≤0.01% + 3 mA ≤0.01% + 3 mA ≤0.01% + 3 mA
Ripple and Noise (20 Hz to 20 MHz, 23°C ± 5°C)
Voltage (V
peak-peak
) 3 mV
peak-peak
4 mV
peak-peak
3 mV
peak-peak
4 mV
peak-peak
Voltage (VRMS) 1 mV
RMS
1 mV
RMS
1 mV
RMS
1 mV
RMS
Current (IRMS) 4 mA 5 mA 4 mA 4 mA
Setting Resolution
Voltage 1 mV 1 mV 1 mV
Current 1 mA 1 mA 1 mA
Setting Accuracy (using remote sense, 23°C ± 5°C)
Voltage ≤0.03% + 10 mV ≤0.03% + 10 mV ≤0.03% + 10 mV
Current ≤0.1% + 5 mA ≤0.1% + 8 mA ≤0.1% + 5 mA ≤0.1% + 5 mA
Readback Resolution
Voltage 1 mV 1 mV 1 mV
Current 1 mA 1 mA 1 mA
Readback Accuracy (23°C ± 5°C)
Voltage ≤0.03% + 10 mV ≤0.03% + 10 mV ≤0.03% + 10 mV
Current ≤0.1% + 5 mA ≤0.1% + 8 mA ≤0.1% + 5 mA ≤0.1% + 5 mA
Temperature Coefficient ±(% of output + offset)/°C
Voltage ≤0.01% + 1 mV ≤0.01% + 1 mV ≤0.01% + 1 mV
Current ≤0.02% + 1 mA ≤0.02% + 1 mA ≤0.02% + 1 mA
