FieldPilot
®
2. MOUNT THE FIELDPILOT VALVE
The FieldPilot valve will mount to the bottom side of the oor of the cab. Use the FieldPilot valve to mark the
location for drilling the two 7/16” mounting holes. The distance between the holes should be 2.9”. Once the
holes are drilled use parts (B, F, & G) to mount the FieldPilot valve. The valve will mount with the solenoids
facing the left side of the machine and the P & T ports facing forward.
Figure 1-4: Mount the FieldPilot Valve
Remove oor mat
View from left side
looking to the right side
B, F & G
F
