Technical Data Sheet

2/13/2015

Model: RKA5510EXD

Product Description

Type: Rotary

Application: HBP/AC - Air Conditioning

Refrigerant: R-22

Voltage/Frequency: 208-230V ~ 60Hz 200V ~ 50Hz

Version: N/A

Product Specifications

Performance

Refrigeration Capacity Input Power Efficiency

Condition Test Voltage Btu/h kcal/h W W Btu/Wh kcal/Wh W/W

EVAP TEMP COND

TEMP

AMBIENT

TEMP

RETURN

GAS

LIQUID

TEMP

ASHRAE 230V ~ 60HZ 10500 2646 3077 960 10.94 2.76 3.2 7.2°C (45°F) 54°C (130°F) 35°C (95°F) 35°C (95°F) 46°C (115°F)

General

Evaporating Temp. Range: -23.3°C to 12.8°C (-10°F to 55°F)

Motor Torque: Low Start Torque (LST)

Compressor Cooling: Fan

Mechanical

Weight: 28

Weight Unit of Measure: LB

Displacement (cc): 14.634

Oil Type: Synthetic Alkylate

Viscosity (cSt): 53

Oil Charge (cc): 356

Electrical

Voltage Range (50 Hz): 180-220

Voltage Range (60 Hz): 197-254

Locked Rotor Amps (LRA): 27

Rated Load Amps (RLA 50 Hz): 0

Rated Load Amps (RLA 60 Hz): 4.3

Max. Continuous Current (MCC in Amps): 7.4

Motor Resistance (Ohm) - Main: 3.03

Motor Resistance (Ohm) - Start: 3.97

Motor Type: PSC

Overload Type: N/A

Relay Type: N/A

Agency Approval

cURus Recognized
