Performance Data Sheet

January 25, 2013
Revision: REL
Specifications/ Parts:
Unit Model
AKA9463ZAADA
Unit Model
AKA9463ZAADG
Unit Bill of Material
2G717-09
Unit Bill of Material
2G717-19
Refrigeration Range
-10° F to +45° F
Receiver Tank
510-10002
Design Pressure Low
181
Liquid Valve
56630
Design Pressure High
450
Suction Valve
56630
Nominal Volts-Hz-Ph
115-60-1
Voltage Range
103-127
Unit Model
AKA9463ZAADH
Min. Circuit Ampacity
16.3
Unit Bill of Material
2G717-29
Max. Fuse Size (amps)
25
Liquid Valve
56630
Suction Valve
56630
Compressor Model
AKA9462ZXA
Comp. Bill of Material
AK172AT-037-P2
Unit Model
AKA9463ZAADK
Compressor RLA/LRA
12.1/68
Unit Bill of Material
2G717-39
Overload
External
Power Cord
85106-14
Relay
820ARR3D10
Run Capacitor
85PR370F20
Unit Model
AKA9463ZAADC
Run Capacitor Rating
25MFD 370V(M) VDE
Unit Bill of Material
2G717-59
Start Capacitor
85PS250C30
Receiver Tank
510-10002
Start Capacitor Rating
72-88 MFD 250V VDE
Liquid Valve
56630
Suction Valve
56630
Fan Motor
810-10004
Power Cord
85106-14
Fan Motor RLA
1.2
Fan Blade
515-10001
Unit Model
AKA9463ZAADS
Fan Shroud/Guard Combo
707-00002
Unit Bill of Material
2G717-69
Condenser
506-00002
Liquid Valve
56630
Suction Valve
56630
Unit Drawing
DGU1970-02
Power Cord
85106-14
Wiring Diagram
91266-02
Unit Model
AKA9463ZAADJ
Replacement Kit: Relay
K71-19
Unit Bill of Material
2G717-79
Replacement Kit: O/L
K71-40
Receiver Tank
510-10002
Liquid Valve
56630
Suction Valve
56630
Filter Drier
70081
Sight Glass
70084
Unit Model
AKA9463ZAADP
Unit Bill of Material
2G717-89
Receiver Tank
510-10002
Liquid Valve
56630
Suction Valve
56630
Power Cord
85106-14
Filter Drier
70081
Sight Glass
70084
