Performance Data Sheet

January 23, 2013
Revision: REL
Specifications/ Parts:
Unit Model
AKA9446ENADA
Unit Model
AKA9446ENADG
Unit Bill of Material
2G215-09
Unit Bill of Material
2G215-19
Refrigeration Range
-10° F to +45° F
Receiver Tank
510-10000
Design Pressure Low
150
Liquid Valve
56630
Design Pressure High
450
Suction Valve
56630
Nominal Volts-Hz-Ph
208/230-60-1
Voltage Range
187-254
Unit Model
AKA9446ENADH
Min. Circuit Ampacity
5.8
Unit Bill of Material
2G215-29
Max. Fuse Size (amps)
15
Liquid Valve
56630
Suction Valve
56630
Compressor Model
AKA9442EXD
Comp. Bill of Material
AK165ET-037-P2
Unit Model
AKA9446ENADK
Compressor RLA/LRA
4.3/31
Unit Bill of Material
2G215-39
Overload
External
Power Cord
85259-5
Relay
820ARR3C29
Run Capacitor
85PR370E36
Unit Model
AKA9446ENADC
Run Capacitor Rating
15MFD 370V(M) VDE
Unit Bill of Material
2G215-59
Start Capacitor
85685
Receiver Tank
510-10000
Start Capacitor Rating
72-88 MFD 330V VDE
Liquid Valve
56630
Suction Valve
56630
Fan Motor
810-10002
Power Cord
85259-5
Fan Motor RLA
.45
Fan Blade
515-10003
Unit Model
AKA9446ENADS
Fan Shroud/Guard Combo
707-00005
Unit Bill of Material
2G215-69
Condenser
506-10008
Liquid Valve
56630
Suction Valve
56630
Unit Drawing
DGU1970-04
Power Cord
85259-5
Wiring Diagram
91266-02
Unit Model
AKA9446ENADJ
Replacement Kit: Relay
K71-17
Unit Bill of Material
2G215-79
Replacement Kit: O/L
K90-16
Receiver Tank
510-10000
Liquid Valve
56630
Suction Valve
56630
Filter Drier
71116
Sight Glass
70084
Unit Model
AKA9446ENADP
Unit Bill of Material
2G215-89
Receiver Tank
510-10000
Liquid Valve
56630
Suction Valve
56630
Power Cord
85259-5
Filter Drier
71116
Sight Glass
70084
