Performance Data Sheet

January 23, 2013
Revision: REL
Celseon® Air Cooled Condensing Unit
Model: AKA9446ENAD*
BoM: 2G215-** R-22 1/2 HP
Model
Dimensions, inches
Line Connection*
Pumpdown
Air
Oil Ch
Gr. Wt.
L
W
H
CH
Suction
Liquid
90 F 90%
SCFM
Oz.
Lbs.
AKA9446ENADA
20.0
14.3
12.1
10.1
3/8” S
1/4” S
N/A
230
15
53
AKA9446ENADG
3/8” S
3/8” S
3.1 lbs
54
AKA9446ENADH
3/8” S
3/8” S
N/A
53
AKA9446ENADK
3/8” S
1/4” S
53
AKA9446ENADC
3/8” S
3/8” S
3.1 lbs
54
AKA9446ENADS
3/8” S
3/8” S
N/A
53
AKA9446ENADJ
3/8” S
3/8” S
3.1 lbs
54
AKA9446ENADP
3/8” S
3/8” S
3.1 lbs
54
* F = Flare, S = Solder, RF or RS = Rotolock with Flare or Solder Connections, C = Compression Fitting
Factory charge: 20 PSIG Nitrogen – MUST BE EVACUATED
Ambient Temperatures
Evaporator T,
90°F
100°F
110°F
°F
PSIG
BTUH
Watts
Cond T
BTUH
Watts
Cond T
BTUH
Watts
Cond T
-10
16.5
1800
510
100
1450
440
108
---
---
---
-5
20.0
2200
560
101
1800
540
110
1400
525
119
0
24.0
2600
600
105
2200
590
113
1750
580
121
5
28.2
3050
620
107
2600
640
116
2150
630
123
10
32.8
3500
690
110
3100
690
117
2600
690
126
15
37.7
4050
730
113
3550
735
120
3100
740
130
20
43.0
4600
780
116
4100
780
124
3600
795
132
25
48.8
5150
820
119
4600
835
127
4100
850
136
30
54.8
5700
870
121
5150
890
130
4700
915
138
35
61.5
6300
920
126
5700
940
133
5200
970
142
40
68.5
6900
965
128
6350
1000
137
5800
1030
145
45
76.0
7600
1020
132
6900
1050
139
6200
1090
147
60 Hz Performance
Return gas temp. 40F, 5F sub cooling
