Technical Data Sheet

Technical Data Sheet
2/13/2015
Model: AGC5561EXG
Product Description
Type: Reciprocating
Application: HBP/AC - Air Conditioning
Refrigerant: R-22
Voltage/Frequency: 460V 3~ 60Hz 380-420V 3~
50Hz
Version: N/A
Product Specifications
Performance
Refrigeration Capacity Input Power Efficiency
Condition Test Voltage Btu/h kcal/h W W Btu/Wh kcal/Wh W/W
EVAP TEMP COND
TEMP
AMBIENT
TEMP
RETURN
GAS
LIQUID
TEMP
ASHRAE 460V 3~
60HZ
61000 15372 17873 6300 9.68 2.44 2.84 7.2°C (45°F) 54°C (130°F) 35°C (95°F) 35°C (95°F) 46°C (115°F)
ASHRAE 380V 3~
50HZ
50800 12802 14884 5250 9.68 2.44 2.84 7.2°C (45°F) 54°C (130°F) 35°C (95°F) 35°C (95°F) 46°C (115°F)
General
Evaporating Temp. Range: -23.3°C to 12.8°C (-10°F to 55°F)
Motor Torque: Low Start Torque (LST)
Compressor Cooling: Fan
Mechanical
Weight: 99
Weight Unit of Measure: LB
Displacement (cc): 112.438
Oil Type: Synthetic Alkylate
Viscosity (cSt): 53
Oil Charge (cc): 1955
Electrical
Voltage Range (50 Hz): 342-462
Voltage Range (60 Hz): 414-506
Locked Rotor Amps (LRA): 62
Rated Load Amps (RLA 50 Hz): 0
Rated Load Amps (RLA 60 Hz): 9.5
Max. Continuous Current (MCC in Amps): 14.8
Motor Resistance (Ohm) - Main: 2.48
Motor Resistance (Ohm) - Start: N/A
Motor Type: 3PH
Overload Type: N/A
Relay Type: N/A
Agency Approval
