TECHNI-TOUCH User’s Guide www.technisat.
Get to know your TECHNI-TOUCH FRONT PANEL _______________________________________________________ • touch screen Tap an icon or item with your finger to quickly navigate across the screen and change values • Power Turn on press the ‘HOME’ key. turn off press and hold the ‘HOME’ key • WHEEL Rotate the wheel to navigate across the screen and to change values.
HOME SCREEN ______________________________________________________ Press the ‘HOME’ key to get to the home screen then touch the ‘SAT’, ‘TV’ or ‘CATV’ icon to select the desired measurement mode.
SAT SAT Analyze Satellite Television Signals SWITCH TO SAT MODE _________________________________________ Go to the home screen, tap the ‘SAT’ icon then select a channel plan. Tap the ‘MEAS’ icon to confirm.
TV TV Analyze Terrestrial Television & Radio Signals SWITCH TO T V MODE ____________________________________________ Go to the home screen, tap the ‘TV’ icon then select a channel plan. Tap the ‘MEAS’ icon to confirm.
CATV CATV Analyze Cable Television Signals SWITCH TO CAT V MODE _______________________________________ Go to the home screen, tap the ‘CATV’ icon then select a channel plan. Tap the ‘MEAS’ icon to confirm.
SPECT SPECT Spectrum Analyzer SWITCH TO SPECT MODE _____________________________________ OR SPECT SPECTRUM ANALYZER SCREENS _______________________ Fast spectrum Touch to cycle through spectrum analyzer screens Fast spectrum with peak memory REL ATED FUNCTIONS _________________________________________ HELP 7 HELP (inspect an unknown signal)
MPEG SERVICE (MPEG LIST service) show and select available mpeg ts services MPEG SERVICE Rotate to Navigate Mpeg service list BARSCAN TILT BARSCAN GRAPH Check all channels level/power BARSCAN Barscan (tilt graph) view 8
HELP HELP Inspect an unknown signal HELP Change “MRK.
MEMORY MEMORY Work with Plan and Log Files MEMORY OR keep pressed 2” AUTOMEMORY ( T V ) _______________________________________________ Set the desired parameters and select “save?” to create a new automemory plan upon automemory completion the new plan is automatically selected LOGGER _________________________________________________________________ Set the desired parameters and select “save?” to create a new log file Set the parameters to select the new log file and select “RECALL” to show it
Volume & Configuration Volume & Configuration Menu TOUCHSCREEN CALIBR ATION _____________________________ in case the touchscreen is not responding proprely you may need to calibrate it: choose ‘configuration menu’ from the volume screen choose ‘meter’ then ‘calibrate touchscreen now touch the center of the box that appears in the corner of the screen, repeat the operation 4 times.
SERVICE NOTES and GUARANTEE REGULATIONS Thank you, that you have choosen our Techni-Touch. We hope you are satisfied with your decision, but if you do have any problem or Suggestions which could lead to an improvement of our field strength meters please write to: TechniSat Digital GmbH Kunden- und Logistikzentrum St. Laurentiusstraße 45 D-54550 Daun Germany www.technisat.
FAULT IDENTIFICATION FORM ✁ DEAR CUSTOMER Please Fill all the Squared Areas. Date:............................................................................................................................. Customer Information. Already TechniSat Customer New TechniSat Customer • Customer Nr.:............................................................................................................. • Name or Company Information:..................................................................
Yes I agree, that TechniSat Digital GmbH can save my Data listed above for their own advertising / direct Marketing purpose. Yes I know, that in addition to my name and address as well as Telephone, Fax and e-mail TechniSat Digital GmbH will also store the Instrument Type and number. Customer Signature:.................................................................................................. The warranty registration will be independent of the above agreement for Advertising / mailing purpose.
MAINTAINING the METER CLEANING THE METER Cleaning the meter from dust and dirt is easy and helps mantaining it in optimal work conditions through the years. The cleaning procedure is simple and quick and requires only minor attention. Never use chemical aggressive products (diluent) and/or abrasive or rough clothes which may damage plastics and displays. Always use a soft cloth, damped with a simple water and alcohol solution or a de-greasing not abrasive liquid soap.
SERVICE and SUPPORT WEB REGISTRATION and SOFTWARE UPGRADES For the TECHNITOOL-SMART Program please go to www.Technisat.
TECHNITOOL S.M.A.R.T. Program 1- The “TECHNITOOL S.M.A.R.T.” program is required to upgrade firmware • Connect the instrument to the mains and turn it on. • Connect the USB cable FIRST to the meter and THEN to the PC. • Start the “TECHNITOOL S.M.A.R.T.” Program. • Click “Instrument” and then “Upgrade Instrument” In the “TECHNITOOL S.M.A.R.T.” program menu. • In the “Open” window, select the file to be used for up-grades and confirm the selection by pressing the “Open” key.
BATTERY IMPORTANT: - ALWAYS TURN THE INSTRUMENT OFF BEFORE CONNECTING THE BATTERY CHARGER. - DO NOT LEAVE THE BATTERIES DISCHARGED FOR LONG PERIODS. - ALWAYS CHARGE THE BATTERIES AT NIGHT FOR AT LEAST 8-10 HOURS, EVEN IF THEY ARE NOT COMPLETELY DISCHARGED. USEFUL INFORMATION: 1.
INDEX 2 4 – SAT Get to know your TECHNI-TOUCH – SAT analyze Satellite Television Signals 5 TV TV analyze Terrestrial Television & Radio Signals 6 CATV CATV Analyze Cable Television Signals 7 SPECT SPECT Spectrum Analyzer 8 MPEG SERVICE LIST show and select available mpeg ts services 8 BARSCAN BARSCAN Check all channels level/power 9 HELP HELP Inspect an unknown signal 9 SPECIAL SPECIAL FUNCTIONS 10 MEMORY – MEMORY Work with Plan and Log Files 11 – Volume & Configuration 12
- NOTES - 20
- NOTES - 21
- NOTES - 22
- NOTES - 23
Technical Hotline Tel. +49 (0) 180/500 59 07 (0,14 €/min on the German network, mobile telephone charges and foreign call charges will differ). UG-TECHNI-TOUCH-EN-V1 Designed in Europe, Assembled in Europe TechniSat Digital GmbH Kunden- und Logistikzentrum St. Laurentiusstraße 45 D-54550 Daun Germany product specification are subject to change without notice . All trademarks used are properties of their respective owners.
