Full HD LCD TV with Freeview User Guide Model No LCD32-250
IDTV IMPORTANT SAFETY INSTRUCTIONS Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Warnings • To reduce the risk of fire, electric shock or damage to the television, do not expose it to dust, rain or moisture, or place any objects filled with liquids on or near the television. • Do not place the television in a confined space, ensure that nothing can obstruct the ventilation openings at the rear of the television.
User Guide IMPORTANT SAFETY INSTRUCTIONS Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Important Information Regarding Use of Video Games, Computers, Captions or Other Fixed Image Displays The extended use of fixed image program material can cause a permanent "shadow image" on the LCD panel. This background image is viewable on normal programs in the form of a stationary fixed image.
IDTV 4
User Guide CONTENTS Important Guarantee Information Important Safety Instructions 1 2-3 What is included in the box 6 Detaching the stand & wall mounting 7 Getting Started - Initial Set Up 9 TV Buttons and Source Menu 10 Remote Control 11 Connections 12-13 TV Menu Operation Picture Menu Sound Menu Channel Menu Feature Menu Setup Menu 14-18 14 15 16 17 18 PC Operation Using the television as a computer monitor PC Settings Menu 20-21 20 21 USB Record / 7 Day TV Guide USB Record USB Record /
IDTV WHAT IS INCLUDED IN THE BOX Accessories Included with this TV are the following accessories: 1 x User Guide 1 x Remote Control 1 x Quick Start Guide 2 x Batteries 1 x TV 1 x Blanking Plate 1 x RF cable 1 x USB Memory Stick Please save your packaging as you will need this in the event of warranty/ service repair or support. We are unable to carry out warranty/service if you are unable to package it correctly.
User Guide DETACHING THE STAND & WALL MOUNTING IMPORTANT - BEFORE DRILLING ANY HOLES IN THE WALL ENSURE YOU ARE NOT DRILLING WHERE THERE COULD BE ANY ELECTRIC WIRES, WATER OR GAS PIPES This television requires a VESA 200 x 400 wall mount, or equivalent. 200 x 400 Detaching the Stand 1) Remove the six screws indicated below Important – If wall mounting this TV, only use the screws already provided in the wall mounting holes.
IDTV 8
User Guide GETTING STARTED - INITIAL SET UP 1) Using the RF cable supplied, connect the TV to the TV Aerial wall socket (Fig A) 2) Connect the power cable to the Electrical outlet (Fig B) Fig B Fig A 3) Switch on the television using the power on/off switch located on the side or underside of the TV. 4) Insert the batteries supplied into the Remote control and press the Power/Standby button to power on the TV On/Off 5) You will now be welcomed with the initial set-up screen.
IDTV TV BUTTONS & SOURCE MENU TV Buttons 1 Volume up and menu right 2 Volume down and menu left 3 Program/Channel up and menu up 4 Program/Channel down and menu down 1 5 Displays Menu/OSD 2 6 Select the input source 3 7 Standby Power On/Off 4 5 6 7 Choosing Mode/Source To switch between the different connections is very easy. Using the buttons on the remote control: 1) Press [SOURCE] - The following will appear 2) Press [\/] or [/\] to select the input you require.
User Guide REMOTE CONTROL STANDBY - Switch on TV when on standby or vice versa MUTE - Mute the sound or vice versa ATV - Switch to analogue TV source TV/RADIO - Switch to Freeview and switch between TV and radio in Freeview mode TV GUIDE - Opens the 7 Day TV Guide (Freeview mode) USB - Switch to USB source REC - To record what is currently on television REC LIST - Opens the list of what you have previously recorded - To return to the start of the recording - To advance to the end of the recording - To sto
IDTV CONNECTIONS Rear Connections A B C D E G F A USB USB port B HDMI 1 HDMI input C HDMI 2 HDMI input D VGA(PC) VGA-PC input E VGA(PC) Audio In 3.
User Guide CONNECTIONS Connecting a Camcorder, Camera or Games Console Source should be set to Video Camera or Camcorder Yellow Video White Audio In L/R Red Connecting a High Definition (HD) Device Option 1 - via HDMI to HDMI cable A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio with minimal loss of picture quality. TV Source should be set to HDMI.
IDTV PICTURE MENU To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll settings press [OK] button. buttons. To confirm any To exit this menu at anytime, press [EXIT] button.
User Guide SOUND MENU To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll settings press [OK] button. buttons. To confirm any To exit this menu at anytime, press [EXIT] button.
IDTV CHANNEL MENU To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll settings press [OK] button. buttons. To confirm any To exit this menu at anytime, press [EXIT] button. Channel Manager - Allows you to lock channels, delete channels, add/remove channel skip and move channel position Favourite Manager - Add and remove favourites.
User Guide FEATURE MENU To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll settings press [OK] button. buttons. To confirm any To exit this menu at anytime, press [EXIT] button. System Lock - This menu allows you to lock certain features of the television so that they can not be used or viewed.
IDTV SETUP MENU To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll settings press [OK] button. buttons. To confirm any To exit this menu at anytime, press [EXIT] button.
User Guide 19
IDTV USING THE TELEVISION AS A COMPUTER MONITOR IMPORTANT – Before connecting the computer to the television you must ensure the computer settings are correct for the television. You MUST do this using your old monitor.
User Guide PC SETUP MENU To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll settings press [OK] button. buttons. To confirm any To exit this menu at anytime, press [EXIT] button.
IDTV USB RECORD Built into this television a USB record facility. The benefits of this are as follows: • • • • Pause live TV/Radio and then playback, fast forward and rewind up to live TV One button record, if you decide you want to record the current program Easy programmable recording from the 7 day TV Guide Record TV/Radio and watch/listen back on your computer/laptop Included with the television is a 4GB USB high speed Memory Stick. This will allow you to record approximate 2 hours of television.
User Guide USB RECORD / 7 DAY TV GUIDE Record from 7 Day TV Guide TV Guide is available in Digital TV mode. It provides information about forthcoming programmes (where supported by the broadcasted channel). You can view the start and end time of all programs and on all channels for the next 7 days, set reminders and plan your recording 1) Press [TV GUIDE]. The following 7 Day TV Guide will appear.
IDTV USB MODE / MEDIA PLAYER Movie Music Photo Recorded Programs USB mode offers playback of various different types of content that you have saved on your USB Memory Stick. On switching to USB source the above menu screen will appear. The content will be divided into Movies, Music, Photos and Recorded Programs based on file type. You can navigate through the menus using the scroll play/view press [OK] button. 24 buttons.
User Guide USING WITH SKY DIGITAL / VIRGIN MEDIA You may wish to use your TV with Sky Digital, Virgin Media or another cable or Satellite box. There are a number of connection options, the best being connecting via SCART cable. Connecting via SCART 1) Connect the SCART cable from the Cable/Satellite Box to SCART of the TV 2) Press [SOURCE] 3) Press [\/] or [/\] to select SCART 4) Press [OK] The channel your Cable/Satellite box is displaying will now be shown on the TV.
IDTV FREQUENTLY ASKED QUESTIONS TV I have tuned in Digital TV but I am not receiving any or all of the channels and/ or the channels I receive are breaking up 1) Check you are in an area that can receive Freeview. Visit www.freeview.co.uk or call 08701 111 270. 2) Check you are using an aerial that is able to receive a good digital signal. In most cases, you will need an outdoor digital hi-gain/wideband aerial.
User Guide TECHNICAL SPECIFICATION Model LCD32-210 Size (Inches) 32" Resolution 1366 x 768 Contrast Ratio 4000:1 2 Brightness cd/m 450 PC RGB Yes RF 75 ohm Antenna / PAL-SECAM Video 2 x SCART, 1 x Video, 1 x S-Video, 1 x Component (YPbPr - 1080i) Sound Inputs 1 x 3.
IDTV INDEX Aspect Ratio Auto Configuration of screen (PC) Auto Volume Level Auto Search Balance Bass Blue Screen Brightness Channel Manager Clock Clock (PC) Colour Colour Temperature Common Interface Connections Contrast Detaching the Stand & Wall mounting Digital Output Digital Switchover Favourites Manager Firmware Update First Time Installation Frequently Asked Questions Getting Started Hearing Impaired Horizontal Position (PC) 18 21 15 16 15 15 18 14 16 17 21 14 14 17 12-13 14 7 15 28-29 16 18 18 26 9
User Guide 29
IDTV 30
User Guide OPTIONAL ACCESSORIES AND REPLACEMENT PARTS Need a replacement part or accessory? Call the helpline on 0871 2000 463 Or visit our online store www.skymediauk.co.uk Ordering via the website is easy and secure, in addition, because we do not have to manually place your order, its also cheaper to order online than over the phone.
IDTV
TESCO Stores Ltd, Cheshunt, EN8 9SL, UK.
