HD Ready LCD TV with Freeview, DVD & USB PVR User Guide Model No LCD22-220
IMPORTANT SAFETY INSTRUCTIONS Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Warnings • To reduce the risk of fire, electric shock or damage to the television, do not expose it to dust, rain or moisture, or place any objects filled with liquids on or near the television. • Do not place the television in a confined space, ensure that nothing can obstruct the ventilation openings at the rear of the television.
IMPORTANT SAFETY INSTRUCTIONS Please read these instructions. All the safety and operating instructions should be read before the appliance is operated. Important Information Regarding Use of Video Games, Computers, Captions or Other Fixed Image Displays The extended use of fixed image program material can cause a permanent “shadow image” on the LCD panel. This background image is viewable on normal programs in the form of a stationary fixed image.
6 TEchnika Manual 19-22-220 .
CONTENTS Manufacturers Guarantee Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5 What is included in the box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8 Attaching / detaching the stand and wall mounting . . . . . . . . . . . . . . . . . . . . . . . . . . .
What is included in the box WHAT IS INCLUDED IN THE BOX Accessories Included with this TV are the following accessories: 1 x User Guide 1 x Remote Control 1 x Quick Start Guide 2 x AAA Batteries HD READY DIGITAL LCD TV/DVD WITH USB RECORD Quick Start Set Up Guide. For full instructions please refer to the user guide. A B Insert the TV into the stand at 45 degrees. Twist the TV into the CLOSE position until it clicks into place.
Attaching / detaching the stand and wall mounting ATTACHING/DETACHING THE STAND Attaching the Stand 1) Insert the TV into the stand at 45 degrees 2) Twist the TV into the CLOSE position until it clicks into place This television requires a VESA 100 wall mount, or equivalent. Detaching the Stand 1) To remove the base, press close and rotate 45 degrees.
10 TEchnika Manual 19-22-220 .
Getting Started - Initial Set Up GETTING STARTED - INITIAL SET UP 1) Using the RF cable supplied, connect the TV to the TV Aerial wall socket (Fig A) 2) Connect the power cable to the Electrical outlet (Fig B) Fig B Fig A 3) Switch on the television using the power on/off switch located on the side of the TV. 4) Insert the batteries supplied into the Remote control and press the Standby button to power on the TV Power on/off 5) You will now be welcomed with the initial set-up screen.
TV Buttons and Source Menu TV BUTTONS & SOURCE MENU 1 Displays the input source menu 2 Displays Menu/OSD 3 Programme/Channel down and menu down 4 Programme/Channel up and menu up 5 Volume down and menu left 6 Volume up and menu right 7 Play/Pause Disc 1 2 3 4 5 6 7 8 9 STANDBY 8 Eject Disc 9 Standby Power On/Off Choosing Mode Input/Source To switch between the different input/ connections.
Remote Control REMOTE CONTROL 1 1 2 3 4 5 STANDBY - Switch on TV when in standby or vice versa MUTE - Mute the sound or vice versa TV/RADIO - Switch to Freeview and switch between TV and radio in Freeview mode TV GUIDE - Opens the 7 Day TV Guide (Freeview mode) ATV - Switch to analogue TV source USB - Switch to USB source DVD - Switch to DVD source EJECT - Eject disc in DVD mode REC - To record what is currently on television REC LIST - Opens the list of what you have previously recorded - To restart
Connections CONNECTIONS A B C E F A HEADPHONES 3.5mm Headphone output B RF IN RF / TV Aerial Input C AUDIO IN (R/L) Component / Video audio input D Component HD Component HD Input E VIDEO Video input F COAX Audio Out Digital Coax output G CI CARD IN Common Interface Card Input H SCART SCART input I VGA(PC) Audio In 3.
Connections CONNECTIONS Connecting a Camcorder, Camera or Games Console Source should be set to Video Camera or Camcorder Yellow Video White Audio In L/R Red Connecting a High Definition (HD) Device Option 1 - via HDMI to HDMI cable A HDMI cable can output both video and audio and enables you to enjoy digital-quality video and audio with minimal loss of quality. TVs Input/Source should be set to HDMI.
TV Menu Operation PICTURE MENU AV To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll To confirm any settings press [OK] button. buttons. To exit this menu at anytime, press [EXIT] button.
TV Menu Operation SOUND MENU AV To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll any settings press [OK] button. buttons. To confirm To exit this menu at anytime, press [EXIT] button.
TV Menu Operation CHANNEL MENU AV To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll any settings press [OK] button. buttons. To confirm To exit this menu at anytime, press [EXIT] button. Channel Manager - Allows you to lock channels, delete channels, add/remove channel skip, move channel position and rename channels. Favourite Manager - Add and remove favourites.
TV Menu Operation FEATURE MENU AV To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll any settings press [OK] button. buttons. To confirm To exit this menu at anytime, press [EXIT] button. System Lock - This menu allows you to lock certain features of the television so that they cannot be used or viewed.
TV Menu Operations SETUP MENU AV To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll buttons. To confirm any settings press [OK] button. To exit this menu at anytime, press [EXIT] button.
DVD Menu DVD MENU AV To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll any settings press [OK] button. buttons. To confirm To exit this menu at anytime, press [EXIT] button.
22 TEchnika Manual 19-22-220 .
PC Operation USING THE TELEVISION AS A COMPUTER MONITOR IMPORTANT – Before connecting the computer to the television you must ensure the computer settings are correct for the television. You MUST do this using your old monitor.
PC Operation PC SETUP MENU AV To access this menu, press [MENU] button on the remote control. If you wish to make changes to any of the default settings, use the scroll any settings press [OK] button. buttons. To confirm To exit this menu at anytime, press [EXIT] button.
USB Record USB RECORD - DIGITAL/FREEVIEW MODE USB RECORD – DIGITAL/FREEVIEW MODE Built into this television is a USB record facility. This function is available in Digital/Freeview mode when used in conjunction with a compatible USB memory stick or USB Hard drive.
USB Record USB RECORD / 7 DAY TV GUIDE Record from 7 Day TV Guide TV Guide is available in Digital TV mode. It provides information about forthcoming programmes (where supported by the freeview channel). You can view the start and end time of all programmes and on all channels for the next 7 days, set reminders and plan your recording 1) Press [TV GUIDE]. The following 7 Day TV Guide will appear.
USB Mode / Media Player USB MODE / MEDIA PLAYER Movie Music Photo Recorded Programmes AV USB mode offers playback of various different types of content that you have saved on your USB Memory Stick. On switching to USB source the above menu screen will appear. The content will be divided into Movies, Music, Photos and Recorded Programmes based on file type. You can navigate through the menus using the scroll play/view press [OK] button. buttons.
General Information USING WITH SKY DIGITAL / VIRGIN MEDIA You may wish to use your TV with Sky Digital, Virgin Media or another cable or Satellite box. There are a number of connection options, the best being connecting via SCART cable. Connecting via SCART 1) Connect the SCART cable from the Cable/Satellite Box to SCART of the TV 2) Press [SOURCE] 3) Press [\/] or [/\] to select SCART 4) Press [OK] The channel your Cable/Satellite box is displaying will now be shown on the TV.
General Information FREQUENTLY ASKED QUESTIONS TV I have tuned in Digital TV but I am not receiving any or all of the channels and/ or the channels I receive are breaking up 1) Check you are in an area that can receive Freeview. Visit www.freeview. co.uk or call 08701 111 270. 2) Check you are using an aerial that is able to receive a good digital signal. In most cases, you will need an outdoor digital hi-gain/wideband aerial.
General Information TECHNICAL SPECIFICATION Model LCD 19-220 LCD 22-220 Screen size (diagonal) 19”/48cm 22”/56cm Resolution 1440 x 900 1680 x 1050 1000:1 1000:1 Brightness cd/m2 300 300 PC RGB Yes Yes Contrast Ratio RF 75 ohm Antenna / PAL-SECAM Video Inputs 1 x SCART, 1 x Video, 1 x Component (YPbPr - 1080i) Sound Inputs 1 x 3.
General Information INDEX Attaching the base/stand............................................... 9 Aspect Ratio.................................................................... 20 Auto Configuration of screen (PC) ................................ 24 Auto Volume Level ........................................................ 17 Auto Search .................................................................... 18 Balance ........................................................................... 17 Bass ....
