SPECIFICATIONS
Tube capacity
6 (large and small in any combination)
24 mini tubes (when using the FHB61 mini tube holder)
96 x 15ml tubes (in holder)
48 x 50ml tubes (in holder)
Maximum temperature* 100°C
Minimum temperature 10°C above ambient
Temperature selection Digital
Adjustable rotation speed 0; 5 to 20 rpm
Adjustable rocking platform (optional) 30 opm recommended
Temperature display LED
Temperature set point resolution 0.1°C
Temperature sensor PRT
Temperature stability in the chamber ≤1.0°C
Temperature stability in the tubes ±0.1°C
Temperature uniformity in the chamber#
±1.5°C
Temperature uniformity in the tubes# ±1.0°C
Temperature accuracy ±0.3°C
External dimensions (W x D x H) 385 x 285 x 555mm
Internal dimensions (W x D x H) 260 x 210 x 330mm
Electrical supply
230V, 50/60Hz
120V, 50/60Hz
Power 750W
Net weight 20kg
Shipping weight 24kg
Note: The HB-1D includes a pre-set, re-settable over-temperature cut-out.
#Temperature measured in the centre of each tube.
*Large tubes are fitted with seals suitable for use up to 70°C. For higher temperatures, seals part
number 6101488 are required.
For the hybridisation tubes see the list under Spares and Accessories
