Item Designations Qty Bin # Description Package

1

U701

1

ICT 52000

IC, temperature sensor, SPI 8-MSOP

2

C701

1

TRM 0006

TRIMMER CAPACITOR, 9-90pF THT

3 C704 1

CAP 17202

CAPACITOR 0.1uF, 50V, 10% SMD 0805

4 C705 1

CAP 08402

CAPACITOR 100pF, 50V, 10% SMD 0805

5 L701 1

IND 0831

INDUCTOR, 0.01uH, 10%, 540mA, 180mohm SMD 0805

6 J701 1

CON 31525

CONNECTOR, header, 0.1", 3-position SMD

7 J702 1

CON 45021

CONNECTOR, modular, jack, 8-8 R/A, shielded

8 S701 1

SWT 0016

SWITCH, 1-position, SPST SMD

9 1

PCB 180

PRINTED CIRCUIT BOARD, FR4, 0.062"

Modified: 11/13/08

Revision: 1.10

Bill of Materials - ASY180C

Circuit: Temperature Sensor (w/ DC Filter UHF)
