Item Designations Qty Bin # Description Package
1
U701
1
ICT 52000
IC, temperture sensor, SPI 8-MSOP
2 C702, C704 2
CAP 17202
CAPACITOR 0.1uF, 50V, 10% SMD 0805
3 C703 1
CAP 11502
CAPACITOR 0.001uF (1000pF), 50V, 10% SMD 0805
4 C705 1
CAP 08402
CAPACITOR 100pF, 50V, 5% SMD 0805
6 J702 1 CON 45021
CONNECTOR, modular, jack, 8-8 R/A, shielded
7 1
PCB 180
PRINTED CIRCUIT BOARD, FR4, 0.062"
Modified: 11/13/08
Revision: 1.10
Bill of Materials - ASY 180A
Circuit: Temperature Sensor (no DC filter)
