User's Manual

Page 1
Item Designations Qty Bin # Description Package
1 U112 1
ICT 32001
IC MICROCONTROLLER 256 BYTE RAM 64QFP
2
C106, C107, C117, C118, C128, C129,
C141, C142, C148, C149, C163 11
CAP 14902
CAPACITOR 0.01 uF 50V 10% SMD 0805
3
C108-116, C119-127, C130-140, C143-
145, C161 33
CAP 17202
CAPACITOR 0.1uF 50V 10% SMD 0805
4 C146, C147 2
CAP 07202
CAPACITOR 33pF 50V 5% SMD 0805
5 R101, R104, R107 R110, R113 5
RES 5012
RESISTOR 2.7KΩ SMD 0805
6 C162 1
CAP 19602
CAPACITOR 1uF, 50V SMD 0805
7 R132 1
RES 6492
RESISTOR 37.4KΩ SMD 0805
8 R133 1
RES 5112
RESISTOR 3.3KΩ SMD 0805
9
R140, R141, R144 R145, R146, R147
R150, R151, R156 9
RES 5802
RESISTOR 10KΩ SMD 0805
10
R134, R135, R136, R137, R138, R139,
R142, R143, R148 R149, R154, R155 12
RES 4502
RESISTOR 1KΩ SMD 0805
11 R152 1
RES 3212
RESISTOR 100Ω SMD 0805
12 R119, R122, R125, R128, R131, R153 6
RES 7042
RESISTOR 100KΩ SMD 0805
13 R158 1
RES 4002
RESISTOR 430Ω SMD 0805
14 R160 1
RES 4662
RESISTOR 1.4KΩ SMD 0805
15 R161 1
RES 6312
RESISTOR 27KΩ SMD 0805
16 R162 1
RES 5512
RESISTOR 6.2KΩ SMD 0805
17 R157 1
RES 1575
RESISTOR 4.7Ω SMD 2010
18
R117, R118, R120 R121, R123, R124
R126, R127, R129 R130 10
RES 0086
RESISTOR 0.006Ω 1% 1W SMD 2512
19 R159 1
POT 0843
POTENTIOMETER 10KΩ 4mm SMD
20
R102, R103, R105 R106, R108, R109
R111, R112, R114 R115 10
RES 2346
RESISTOR 20
Ω 1W SMD 2512
21 RN101 1
RES 5810
RESISTOR NETWORK 10KΩ SMT
22 F107 1
FUS 2901
RESETTABLE FUSE, POLYFUSE, 2A SMD
23 F108 1
FUS 1651
RESETTABLE FUSE, POLYFUSE, .5A SMD
24 L106, L107, L108, L109, L110 5
IND 0221
INDUCTOR 0.01uH 1210
25 Y101 1
CLK 0002
6.00 MHz CRYSTAL SMT
26 U111 1
ICT 56001
IC SUPERVISOR 2.70V LOW SOT23
27 U114 1
ICT 12000
IC TXRX 3.3V CAN 8-SOIC
28 U113 1
ICT 12001
IC CAN CONTROLLER W/SPI 18-SOIC
29 U115 1
ICT 48003
IC REG SIMPLE SWITCHER TO-263-5
30 U116 1
SEM 69000
IC DARL TRANS ARRAY 16-SOIC
31 U117 1
ICT 48004
IC REG LINEAR LDO SOT223
32 U118 1
ICT 16000
IC VOLTAGE COMVERTER 8-SOIC
Bill of Materials
Modified: 08/03/06
Circuit: User Interface Module (TV)
Revision: 1.03
