Specifications

Electrical specifications that are specific to the unit are included with the shipment in addition to

being kept on file at Technalogix.

Physical Characteristics

Power Requirements

Power Supply

220 V

, 11 A

Operating Temperature

0 - 50°C

Dimensions

TAVD-500 Power Amplifier

W-19" flange (17” encl.), D-25-

¼", H-101/2”

(6U)

Filter

W-19" flange (17” encl.), D-25-

¼", H-8-¾”

(5U)

Power Supply

W-19" flange (17” encl.), D-25-

¼", H-5-1/4”

(3U)
