Rear Suspension
后悬吊系统
Bag-E
13
ANTI -SQUAT
TOE -IN
RF
=3.5°
=2.5°
=1.5°
=2.5°
=1.5°
=0.5°
=4°
=3°
=2°
RR
RF
RR
RF
0°
1°
0°
1°
1°
X2 X2
X2 X2
X2
M3x16螺丝
M3x16 Screw
T08673
4x71摆臂轴
4x71 Arm Shaft
T08945
0度轴套-右
0 Degree Bushing-Right
T08944
0度轴套-左
0 Degree Bushing-Left
T08944
1度轴套
1 Degree Bushing
T08944
摆臂固定座-RR
Arm Mount-RR
T08943
摆臂固定座-RF
Arm Mount-RF
T08942
M3x12螺丝
M3x12 Screw
T08674
M3x35螺丝
M3x35 Screw
T08674
…….2
……2
……...........................2
……….2
M3x16 螺丝
T08673
M3x16 Screw
M3x35 螺丝
T08674
M3x35 Screw
M3x12 螺丝
T08674
M3x12 Screw
4x71摆臂轴
T08945
4x71 Arm
Shaft
