尺寸：

T8TE V2

1:8 Scale ELECTRCC OFF ROAD TRUGGY

Length …………………………………………………………………………580mm

Width …………………………………………………………………………430mm

Height …………………………………………………………………………200mm

長度

寬度

高度

Dimensions

Instruction manual

www.teamcracing.net

Summary of content (34 pages)

PAGE 1
www.teamcracing.
PAGE 2
Transmitter Preparation 調整遙控器 1 6 7 11 9 13 8 2 14 10 12 3 GLG20 2.4GHz 4 5 Transmitter Battery Installation 遙控器電池安裝 Open battery cover at the bottom of transmitter. Install batteries. Follow the direction of batteries designated in the inside of battery box.
PAGE 3
Transmitter Preparation 調整遙控器 Battery 電池 Motor 馬達 Battery Charger (Not Included) 1. Install Transmitter Batteries 安裝發射電池 2. Connect Battery to ESC Electronic Speed Controller / Switch 電子變速器連接電池到電調 3. Switch on Transmitter First Servo 伺服首先接通發射機 4.
PAGE 4
1 Servo Saver Turnbuckle 伺服拉杆 Bag-A Select the servo horn matching the servo being used. 根据伺服机选择伺服臂 1:1 x1 approx.33mm 大约33mm TG8019 3x45 Turnbuckle 3x45拉杆 …….......1 T08606 5.8 Ball End 5.8球头座 ▲Projection.Note direction 注意方向 Futaba-25T Hitec-24T Sanwa/JR/KO-23T T08666 ……........2 T08606 5.8 Ball Stud 5.8球头 4mm ...........................2 T08666 M3 Nylon Nut M3尼龙螺母 ...........................1 T08674 M3x15 Screw M3x15螺丝 T08620 Steering Servo Horn-F 转向伺服臂-F T08606 5.8 Ball End 5.8球头座 ……..
PAGE 5
3 Servo Saver Post/Side Plate 缓冲柱/侧板 Bag-A/B TG8003 Side Plate-Right 侧板-右 TG8060 Chassis 底盘 T08955 Servo Saver Post T08674 缓冲柱 M3x8 Screw M3x8螺丝 T08674 M3x8 Screw M3x8螺丝 …….............7 T08674 M4x10 Screw M4x10螺丝 TG8003 Side Plate-Left 侧板-左 T08674 ……......2 M4x10 Screw M4x10螺丝 4 Buffer 缓冲 Bag-A T08674 M3x14 Screw M3x14螺丝 T08674 M4x10 Screw M4x10螺丝 T08941 Buffer Plate-Plastic 缓冲顶板-塑胶 T08666 M3 Nylon Nut M3尼龙螺母 TG8006 B061003 6x10x3 Washer 6x10x3垫片 ……...............
PAGE 6
5 Front/Rear Differential 前/后差速器 T08633 x2 Bag-C T08633 T08633 20T Diff Gear 2.5x11.5 Pin 10T Diff Gear 20T差速齿轮 T08636 T08633 W41202 10T差速齿轮 T08633 W61102 Diff Shaft 2.5x11.5钢针 M3x12螺丝 20T差速齿轮 2.5x11.5钢针 T08633 2.5x11.
PAGE 7
Front Swaybar 前防倾杆 Bag-D x2 T08606 T08606 M3x3 Screw M3x3螺丝 T08601 M2.5x8 Screw M2.5x8螺丝 ……………....3 T08606/T08601 M3x3 Screw M3x3螺丝 ………………………4 T08606 6.8 Ball Stud 6.8球头 …………………2 T08606 6.8 Ball Stud 6.8球头 T08601 M2.5x8 Screw M2.5x8螺丝 ……………………….2 T08606 6.8 Ball End 6.8球头座 M3x3 Screw Front Hub Carrie 前轮座 Front Swaybar Swaybar Mount L R ……………...2 前防倾杆防倾杆固定座 M3x3螺丝 8 T08647 T08601 T08601 Bag-D Left Right Left TG8018 T08603 2.5x12.8 Pin Front Hub Carriers 12 Degree 2.5x12.
PAGE 8
9 Front Hub Carrie 前轮座 L R Bag-D T08675 M4x10 Screw T08751 M4x10螺丝 Front Hub Carrier Bushing 前轮座轴套 T08751 Front Hub Carrier Bushing 前轮座轴套 ……….4 T08675 M4x10 Screw M4x10 螺丝 TG8001 Front Lower Arm …………….2 T08751 M4x16 Screw M4x16 螺丝前下摆臂 T08751 M4x16 Screw ……4 M4x16螺丝 Suspension 10 Front Bag-D 前悬吊系统 T08645 4x73 Arm Shaft 4x73摆臂轴 …….2 T08674 M3x35 Screw M3x35 螺丝 T08673 M3x16 Screw M3x16螺丝 TU0839 Arm Mount-FR 摆臂固定座-FR T08674 M3x15 Screw M3x15螺丝 ………….
PAGE 9
Shock Tower 11 Front Bag-D 前避震架 TG8005 Front Body Mount 前车壳柱 T08673 M3.5x25 Screw M3.5x25螺丝 T08622 Shock Top Ball Stud 避震上球头 T08673 M3x12 Screw M3x12螺丝 T08674 TG8012 M3x12 Screw Front Shock Tower M3x12螺丝前避震架 T08673 M3.5x25 Screw M3.5x25 螺丝 T08674 M3x12 Screw M3x12 螺丝 T08622 Shock Top Ball Stud 避震上球头 ………2 ………4 ……..2 Upper Turnbuckle 12 Front Bag-D 前上拉杆 1:1 x1 T08673 M3x12 Screw M3x12 螺丝 ………2 Approx.69.5mm 大约69.5mm Front Upper-Left 前上-左 ▲Projection.Note direction 注意方向 Approx.69.
PAGE 10
Turnbuckle 13 Steering 转向拉杆 Bag-D 1:1 x1 Approx.64.5mm 大约64.5mm Steering-Left 转向-左 ▲Projection.Note direction 注意方向 Approx.64.5mm 大约64.5mm 1:1 x1 Steering-Right 转向-右 ▲Projection.Note direction 注意方向 T08606 TG8020 6.8 Ball Stud 4x86 Turnbuckle 6.8球头 5m 4x86拉杆 m T08606 6.8 Ball End-Steering 6.8 球头座-转向 TG8020 4x86 Turnbuckle 4x86 拉杆 T08606 6.8 Ball stud 6.8球头 T08606 6.8 Ball End-Steering 6.
PAGE 11
Suspension 15 Front Bag-D 前悬吊系统 T08674 T08666 M4x10 Screw M4x10螺丝 M3 Nylon Nut M3尼龙螺母 T08674 M3x16 Screw T08674 M3x16 Screw M3x16 螺丝 M3x16螺丝 T08674 .........2 T08674 M4x10 Screw M4x10 螺丝 .............2 T08674 M4x14 Screw M4x14 螺丝 ...........4 M4x14 Screw M4x14螺丝 TG8032 Front Bumper 前防撞板 T08666 M3 Nylon Nut M3尼龙螺母 ...........................2 Differential 16 Center 中央差速器 Bag-C T08600 5.8x1.9 O-Ring 5.8x1.9 O环 T08633 20T Diff Gear 20T差速齿轮 …………………1 W41202 4x12x0.2 Washer 4x12x0.
PAGE 12
Differential 17 Center Bag-C 中央差速器 T08636 5.8x1.9 O-Ring 5.8x1.9 O环 T08633 2.5x11.5 Pin 2.5x11.5钢针 …………………1 W61102 6x11x0.2 Washer 6x11x0.2垫片 T08633 20T Diff Gear 20T差速齿轮 W61102 6x11x0.2 Washer T08916 6x11x0.2垫片 M3x12 Screw T08600 M3x12螺丝 Differential Pads …………........1 B081605 8x16x5 Ball Bearing 8x16x5轴承 T08636 差速垫片 5.8x1.9 O-ring 5.8x1.9 O环 T08916 Center Diff Gear Mount 中差齿轮座 T08915 ………..1 T08916 M3x12 Screw M3x12螺丝 46T Center Diff Gear-Plastic 46T中差齿轮-塑胶 B081605 ……..........
PAGE 13
19 Motor Bag-C 马达 Motor 马达 X TG8061 Motor Mount 马达固定座 Tighten the screws with one sheet of paper inserted between both gears. 两齿轮之间的间隙大约为一张普通纸的厚度。 H393 Motor Gear-16T 马达齿-16T H393 M4x4 Screw TG8061 M4x4螺丝 TG8061 M4x14 Screw TG8055 M3x14 Screw M3x14螺丝 M3x14 Screw M4x14螺丝 …….2 TG8055 M4x14 Screw M4x14螺丝 M3x14螺丝 TG8061 3x7x0.8 Washer 3x7x0.8垫片 ……...2 TG8055 3x7x0.8 Washer 3x7x0.8垫片 ………………..
PAGE 14
Differential 21 Rear Bag-C/E 后差速器 TG8017 132mm Center Rear CVD 132mm中后CVD TG8017 M5x4 Screw M5x4螺丝 T08601 Differential Case 差速箱 B061305 6x13x5 Ball Bearing 6x13x5轴承 B061305 6x13x5 Ball Bearing 6x13x5轴承 W131602 13x16x0.2 Washer 13x16x0.2垫片 ………….2 W131602 13x16x0.2 Washer 13x16x0.2垫片 T08636 10T Gear 10T齿轮 …………..2 T08673 M3x16 Screw M3x16螺丝 T08601 ……..2 Differential Case TG8017 M5x4 Screw M5x4螺丝差速箱 T08673 ………………..1 M3x16 Screw M3x16螺丝 Swaybar 22 Rear Bag-E 后防倾杆 T08601 M2.
PAGE 15
Hub Carrie 23 Rear 后轮座 L R Bag-E TG8018 132mm Drive Shaft Left 132mm传动轴 TG8018 Right 5x8.5 Shaft 5x8.5轴 TG8018 5x8.5 Shaft 5x8.5轴油O il T08605 Rear Hub Carriers TG8018 后轮座 2.5x12.8 Pin 2.5x12.8钢针 T08772 CVD Connecting Cup ……………………2 TG8015 2.5x16.8 Pin 2.5x16.8钢针 ……………2 T08675 M4x4 Screw M4x4螺丝 ………………….2 TG8018 2.5x12.8 Pin 2.5x12.8钢针 ………………2 B131904 13x19x4 Ball Bearing 13x19x4轴承 CVD接杯 TG8015 2.5x16.8 Pin B131904 2.5x16.
PAGE 16
Suspension 25 Rear Bag-E 后悬吊系统 T08943 Arm Mount-RR T08944 摆臂固定座-RR T08674 M3x35 Screw M3x35螺丝 0 Degree Bushing-Right 0度轴套-右 T08673 M3x16 Screw M3x16螺丝 T08944 0 Degree Bushing-Left 0度轴套-左 T08945 4x71 Arm Shaft T08944 4x71摆臂轴 1 Degree Bushing 1度轴套 T08942 Arm Mount-RF 摆臂固定座-RF T08674 M3x12 Screw M3x12螺丝 X2 X2 T08674 M3x12 Screw M3x12 螺丝 1° 0° T08674 M3x35 Screw M3x35 螺丝 ……...........................2 ……….
PAGE 17
T08622 Shock Tower 26 Rear Bag-E 后避震架 T08673 M3.5x25 Screw T08674 M3x10 Screw M3x10 螺丝 Ball stud 球头 T08673 M3x12 Screw M3x12螺丝 M3.5x25螺丝 ………..........2 T08674 TG8005 T08673 M3x6 Screw M3x6 螺丝 M3x10 Screw Rear Body Mount M3x10螺丝后车壳柱 ………..........4 T08673 M3x12 Screw M3x12 螺丝 ………..........2 TG8013 T08673 M3.5x25 Screw M3.5x25 螺丝 ……...2 T08622 Shock Top Ball Stud 避震上球头 Rear Shock Tower 后避震架 TG8004 Dirtcover Rear-Right 后挡泥板-右 ……....
PAGE 18
Upper Turnbuckle 28 Rear 后上拉杆 Bag-E 1:1 x1 Approx.55mm 大约55mm Rear Upper-Left 后上-左 ▲Projection.Note direction 注意方向 Approx.55mm 大约55mm 1:1 x1 Rear Upper-Right 后上-右 ▲Projection.Note direction 注意方向 T08606 7.8 Ball End-Rear Upper 7.8 球头座-后上 T08606 T08606 7.8 Ball Stud TG8021 7.8 Ball Stud 7.8球头 5mm TG8021 5x80 Turnbuckle 5x80 拉杆 7.8球头 5x80 Turnbuckle 5x80拉杆 T08606 7.8 Ball stud T08606 7.8 Ball stud 7.8 球头 7.8 球头 T08606 7.8 Ball End-Rear Upper 7.
PAGE 19
Suspension 30 Rear Bag-E 后悬吊系统 T08666 M3 Nylon Nut M3尼龙螺母 T08674 M3x10 Screw M3x10螺丝 …….............1 T08674 M3x12 Screw M3x12螺丝 ……........1 T08674 M4x14 Screw M4x14螺丝 T08674 M3x12 Screw M3x12螺丝 T08674 M4x14 Screw ……......4 M4x14螺丝 T08666 M3 Nylon Nut M3尼龙螺母 T08674 M3x10 Screw M3x10螺丝 ...........................1 31 Shock Bag-F 避震器 F R x2 T08625/T08626 T08627 2.75mm Plastic Washer 2.75mm塑胶垫片 Shock Bottom Cover 避震下盖 …………………4 T08627 1mm Plastic Washer 1mm塑胶垫片 T08666 M2.
PAGE 20
32 Shock 避震器 Bag-F F R x2 T08623 Shock Boot 避震防尘套 # 450 T08625/T08626 TU0854 Front-Short Shock Top Cover Front Shock Spring-Hard 前-短避震上盖前避震弹簧-硬 TU0856 Rear-Long 后-长 Rear Shock Spring-Hard T08627 后避震弹簧-硬 Diaphragm 气室 Front-Short 前-短 Front-Short 前-短 Rear-Long 后-长 T08622 Rear-Long Spring Mount 后-长弹簧固定座 T08625/T08626 18.5x1.5 O-ring 18.5x1.5 O环 T08625/T08626 18.5x1.5 O-Ring 18.5x1.
PAGE 21
Shock 34 Rear 后避震器 L Bag-F R T08666 T08622 M3.5 Nylon Nut Plastic Bushing M3.5尼龙螺母 T08666 M3.5 Nylon Nut M3.5尼龙螺母 ……................2 T08622 Plastic Bushing 塑胶衬套塑胶轴套 W3591 3.5x9x1 Washer 3.5x9x1垫片 ……......................2 W3591 3.5x9x1 Washer 3.5x9x1垫片 T08673 ……...............2 T08673 M3x18 Screw M3x18螺丝 M3x18 Screw M3x18螺丝 ……2 35 Receiver/Servo Bag-B/J 接收机/伺服机 T08822 W3708 3x7x0.8 Washer 3x7x0.8垫片 Receiver 接收机 ………………..4 T08673 M3x8 Screw M3x8螺丝 …………..
PAGE 22
36 Receiver/Servo Bag-B 接收机/伺服机 T08674 M3x10 Screw M3x10螺丝 ……………4 X T08674 M3x10 Screw M3x10螺丝 x2 Bag-B 37 Battery 电池 Battery 电池 X T08821 Battery Mount 电池固定座 T08821 Velcro Tape 魔鬼粘 X Must be purchased separately 需另购物品 x2 Assemble as many times as specified 需组装数量 19
PAGE 23
38 Battery 电池 Bag-B T08674 M3x8 Screw M3x8螺丝 ................
PAGE 24
40 Wing Bag-G 尾翼 T08674 M3x12 Screw T08674 M3x12 Screw M3x12螺丝 M3x12螺丝 ……………2 T08940 Wing Screw Washer 尾翼螺丝垫片 T08940 Wing 尾翼 41 Tyre 轮胎 x4 Bag-H Tyre 轮胎 X e Glu 胶水 Sponge 海绵 X TG8009 Rim 轮框 x4 x4 Assemble as many times as specified 需組裝數量 X Must be purchased separately 需另购物品 21
PAGE 25
42 Tyre 轮胎 L R Bag-D/E TG8015 17mm Hex Nut 17mm六角螺帽 ……4 TG8015 17mm Hex Nut 17mm六角螺帽 43 Body Bag-I 车壳 TG8000 Body-Lexan 车壳-PC L Assemble both Left and Right R 组装左和右 22
PAGE 26
44 Body 车壳 Bag-J Mask the windows from the inside. 在车窗內壁贴上遮盖贴纸。 Paint the body shell from the inside using spray colors. 在车壳内壁喷漆。 45 Body Bag-J 车壳 T08660 Mid Clip 中号固定夹 …..
PAGE 27
T08822 T02087 T02087 T08675 T08822 W3708 T08793 T08666 T08673 T08625 T08627 T08625 T08627 T08625 T08622 TU0854 T08625 T08623 T08673 T08606 T08675 T08751 T08604 T08603 T08675 B131904 T08772 T08666 T08603 T08956 T08954 T08606 T08953 T08666 T08673 TG8020 TG8001 T08673 T08751 T08606 TG8022 T08606 T08674 T08651 W3708 T08666 T08953 T08674 T08666 T08633 TG8015 B081605 T08666 T08955 TG8019 T08674 T08606 T08620 T08666 T08674 T08601 T08941 T08606 TG8009 TG8020 B06100
PAGE 28
Parts list for T8TE V2 Truggy-1 TG8017 TG8016 TG8060 TG8003 T8TE V2卡车配件包-1 H393 M5x4 Screw M5x4 Screw 螺丝 1pcs 螺丝 1pcs Side Plate-Left M4x4 Screw 1pcs 侧板-左 1pcs Side Plate-Right 侧板-右 1pcs Chassis 87mm Center Front CVD 132mm Center Rear CVD 底盘 1pcs 87mm中前CVD 1pcs 132mm中后CVD 1pcs T08603 T08601 T08600 螺丝 2pcs T08604 Left 1pcs King Pin Bushing 大王销轴套 4pcs M3x3 Screw 1pcs 1pcs Motor Gear-13T 马达齿-13T 1pcs 1pcs Right 1pcs 1pcs M2.
PAGE 29
Parts list for T8TE V2 Truggy-2 20T Diff Gear 20T差速齿轮 2pcs Front Shock Tower Rear Shock Tower 6x11x0.2 Washer 6x11x0.2垫片 2pcs Diff Shaft 差速轴 2pcs 2.5x11.5 Pin 2.5x11.5钢针 2pcs T08915 T08637 T08636 T08635 4x12x0.2 Washer 4x12x0.
PAGE 30
Parts list for T8TE V2 Truggy-3 T8TE V2卡车配件包-3 T08674 M2.5x8 Screw 螺丝 8pcs M3x14 Screw 螺丝 8pcs M3x8 Screw 螺丝 8pcs M3x10 Screw 螺丝 8pcs M4x10 Screw 螺丝 8pcs M3x16 Screw 螺丝 8pcs M3x12 Screw 螺丝 8pcs M3x18 Screw 螺丝 8pcs M3x15 Screw 螺丝 8pcs M4x12 Screw 螺丝 8pcs M3x35 Screw 螺丝 8pcs M4x14 Screw 螺丝 8pcs T08679 T08676 M2.5x8 Screw 螺丝 8pcs M3x14 Screw 螺丝 8pcs M3x18 Screw 螺丝 8pcs M2.
PAGE 31
Parts list for T8TE V2 Truggy-4 3x45 Turnbuckle 3x45拉杆 2pcs T08779 5x96 Turnbuckle 5x96拉杆 2pcs 5x80 Turnbuckle 5x80拉杆 2pcs 4x86 Turnbuckle 4x86拉杆 2pcs 3x51.5 Arm Shaft 3x51.5摆臂轴 2pcs T08822 T08821 TG8031 T08945 TG8022 TG8021 TG8020 TG8019 T8TE V2卡车配件包-4 TU0880 Receiver Cover 接收机盖 1pcs 1mm 2pcs Battery Mount 电池固定座 2pcs 1.5mm 2pcs 2mm 2pcs 4x71 Arm Shaft Center Differential Plate 4x71摆臂轴 2pcs 中央差速器固定板 1pcs T08786 M2.5 Nylon Nut M2.5 尼龍螺母 T08787 M3.5 Nylon Nut M3.
PAGE 32
Parts list for T8TE V2 Truggy-5 TU0886 T08762 T08955 T08954 T8TE V2卡车配件包-5 OP TU0875 OP 1pcs Rear Chassis Stiffener Mount Servo Saver Body 后支撑杆固定座缓冲筒身 1pcs Servo Saver Post 缓冲柱 2pcs Servo Saver Nut 缓冲螺母 1pcs TU0804 Top 1pcs Left 1pcs OP TU0807 Bottom 1pcs OP H394 OP Rear Wing Mount-Shaft 后尾翼座-轴 2pcs H395 TU0829 OP 1pcs Aluminium Motor Washer 4MM 铝马达垫片4MM 1pcs TU0830 OP 1pcs 1pcs 1pcs Front Hub Carriers 12 Degree 前轮座14度前轮座12度 OP TU0877 TU0831 OP TU0819 OP TU0842
PAGE 33
Driver T8TE V2 Track / City Event SETUP SHEET for the TeamC T8TE V2 Track Condition Sandy Smooth Soft dirt Bumpy Grass Hard soil Date Low traction Clay / Med traction Wet Dry Other Front Shocks mm ° Camber 2 3 1 3 mm 2 1 1 2 High traction Dusty Front Suspension Shock Mounting&Camber link Anti-roll bar: / Degree 3 ° Spring Ride height 1 2 Rear Suspension 1 2 mm 4 1 2 1 2 4 3 wt mm 1 3 ° Oil Piston # Rear Shocks Shock Mounting&Camber link Anti-roll bar: Camber
PAGE 34
www.teamcracing.
