User manual

7
TDK-Lambda
LS 25-150 Series
INSTRUCTION MANUAL
LS50-3.3, -5, -12, -15, -24, -36 & -48
LS75-3.3, -5
Output Deratin
g
Vs Ambient Temperature
0
20
40
60
80
100
120
-25 0 25 50 75
100
Ambient Temperature (°C)
Load (%)
Mounting
Mounting
A, B & D
C
70
70
60
45
Output Derating Vs Ambient Temperature
0
20
40
60
80
100
120
-25 0 25 50 75
100
Ambient Temperature (°C)
Load (%)
Mounting
Mounting
A, B & D
C
40 60
70
50
70
