LS 25-150 Series
INSTRUCTION MANUAL
LS100-12, -15, -24, -36 & -48
LS150-3.3, -5
Output Deratin
g
Vs Ambient Temperature
0
20
40
60
80
100
120
-25 0 25 50 75
100
Ambient Temperature (°C)
Load (%)
Mounting
Mounting
A
B, C & D
50
70 30
40
Output Derating Vs Ambient Temperature
0
20
40
60
80
100
120
-25 0 25 50 75
100
Ambient Temperature (°C)
Load (%)
Mounting
Mounting
A & B
C & D
50
70
45
