Data Sheet

i6A4W Series
2
Notes
See website for detailed specifi cations, test methods and installation manual
(1) Output voltage cannot exceed input voltage (see graphs below).
(2) Full Feature module but without the SEQ pin installed.
Specifi cation
Output vs Input Voltage Operating Range
Model i6A4W010A033V i6A4W020A033V
Environmental
Operating Temperature °C -40 to 125 (see thermal data on website)
Storage Temperature °C -55 to 125
Cooling - Convection or forced air
Other
Weight g 15
Size (LxWxH) mm DIP Version: 33 x 22.9 x 12.1, SIP Version: 33 x 11.4 x 24.8
Size (LxWxH) In DIP Version: 1.30 x 0.9 x 0.74, SIP Version: 1.30 x 0.45 x 0.98
Warranty yrs 3
i6A4W10A
Output vs Input Voltage Operating Range
i6A4W20A
