User's Manual

TUNet
®
DA-1710 Quick Reference
TUNet
®
LAN Module Network Status LED (Red)
Start-up/Power-up
Solid ON (Fast flashing indicates module is not programmed)
Unassociated/Re-associating
Solid ON
Valid association candidate found
Flashing
Full network association confirmed
OFF
TUNet
®
LAN Module Serial Activity/Configuration LED (Blue)
Start-up/Power-up
OFF during boot-up. Begins flashing for 30 seconds while in
serial port configuration mode
Normal operation
Flashes with serial activity
TUNet
®
LAN Module Transceiver (XVR) LED (Amber)
Start-up/Power-up
OFF
RF packet transmitted
Long flash
RF packet received (LAN activity)
Short flash
Specifications
Frequency Range: 902-928 MHz frequency hopping,
license exempt
Operating Temperature: -22 to 158°F (-30 to +70°C)
Modulation: FSK
Operating Humidity: 5 to 95% non-condensing
Power supply: 10 – 15VDC
Standards:
Power consumption: Quiescent 0.75 watts typical
FCC CFR Title 47 Part 15b (unintentional radiators)
Industry Canada RSS-210
