The settings library
SIP Profile [1..1] URI [1..1]: <S: 0, 255>
The SIP URI or number is used to address the system. This is the URI that is registered and used by the
SIP services to route inbound calls to the system. A Uniform Resource Identifier (URI) is a compact string of
characters used to identify or name a resource.
Example: “sip:name@example.com”, “1234”, “1234@example.com”
Format: Compact string with a maximum of 255 characters.
Example: SIP Profile 1 URI 1: “sip:name@example.com”
SIP Profile [1..1] DefaultTransport: <UDP/TCP/TLS/Auto>
Select the transport protocol to be used over the LAN.
UDP: The system will always use UDP as the default transport method.
TCP: The system will always use TCP as the default transport method.
TLS: The system will always use TLS as the default transport method. For TLS connections a SIP CA-list
can be uploaded using the web interface. If no such CA-list is available on the system then anonymous Diffie
Hellman will be used.
Auto: The system will try to connect using transport protocols in the following order: TLS, TCP, UDP.
Example: SIP Profile 1 DefaultTransport: Auto
SIP Profile [1..1] TlsVerify: <On/Off>
For TLS connections a CA-list can be uploaded from the web interface.
On: Set to On to verify TLS connections. Only TLS connections to servers, whom x.509 certificate is
validated against the CA-list, will be allowed.
Off: Set to Off to allow TLS connections without verifying them. The TLS connections are allowed to be
set up without verifying the x.509 certificate received from the server against the local CA-list. This should
typically be selected if no SIP CA-list has been uploaded.
Example: SIP Profile 1 TlsVerify: Off
SIP Profile [1..1] Type: <Auto/Nortel/Microsoft/Cisco/Alcatel/Experimental/Avaya/
Siemens>
Enables SIP extensions and special behaviour for a vendor or provider
Auto: Should be used when registering to standard SIP proxy like OpenSer.
Nortel: Must be used when registering to a Nortel MCS 5100 or MCS 5200 PBX.
Microsoft: Must be used when registering to a Microsoft LCS or OCS server.
Cisco: Must be used when registering to a Cisco CallManager version 5 or later.
Alcatel: Must be used when registering to a Alcatel-Lucent OmniPCX Enterprise R7 or later.
Siemens: Must be used when registering to a Siemens HiPath 8000.
Telio: Must be used in combination with a Telio subscription (www.telio.no).
Experimental: Can be used if auto is not working Note! This mode is for testing purposes only.
Example: SIP Profile 1 Type: Auto
SIP Profile [1..1] Proxy [1..1] Discovery: <Auto/Manual>
Manual: When Manual is selected, the manually configured SIP Proxy address will be used
Auto: When Auto is selected, the SIP Proxy address is obtained using Dynamic Host Configuration Protocol
(DHCP).
Example: SIP Profile 1 Proxy 1 Discovery: Manual
SIP Profile [1..1] Proxy [1..1] Address: <S: 0, 255>
The Proxy Address is the manually configured address for the outbound proxy. It is possible to use a fully
qualified domain name, or an IP address. The default port is 5060 for TCP and UDP but another one can be
provided.
Format: Compact string with a maximum of 255 characters.
Example: SIP Profile 1 Proxy 1 Address: “”
SIP Profile [1..1] Authentication [1..1] LoginName: <S: 0, 50>
This is the user name part of the credentials used to authenticate towards the SIP proxy.
Format: String with a maximum of 50 characters.
Example: SIP Profile 1 Authentication 1 LoginName: “”
SIP Profile [1..1] Authentication [1..1] Password: <S: 0, 50>
This is the password part of the credentials used to authenticate towards the SIP proxy.
Format: String with a maximum of 50 characters.
Example: SIP Profile 1 Authentication 1 Password:
The SIP Profile settings
The Standby settings
Standby Control: <On/Off>
The Standby Control setting determines whether the system should go into standby mode or not.
On: The system will go into standby mode when the Standby Delay has timed out. Requires the Standby
Delay to be set to an appropriate value.
Off: The system will not go into standby.
Example: Standby Control: On
Standby Delay: <1..480>
Defines how long (in seconds) the system will wait before it goes into standby mode. Requires the Standby
Control to be enabled.
Range: 1-480 seconds
Example: Standby Delay: 10
