Codec C90 Administrator Guide
Table Of Contents
- Introduction
- Getting started
- About the menus
- The Settings menu
- Administrator Settings Library
- Description of the administrator settings
- The Audio settings
- The Camera settings
- The Conference settings
- The Do not disturb setting
- The H323 Profile settings
- The Network settings
- The Camera settings
- The Phone book server settings
- The Provisioning settings
- The Serial port settings
- The SIP Profile settings
- The Standby settings
- The System unit settings
- The Time zone setting
- The Video settings
- The Experimental menu
- Description of the administrator settings
- Cameras
- Appendices
- General room guidelines
- Guidelines for the executive meeting room
- Guidelines for the high end meeting room
- The Video Input Matrix
- Software upgrade
- Upload certificates
- XML files
- Log files
- NTP Time Zone expressions
- Supported RFCs in SIP
- TANDBERG Remote Control TRC5
- TANDBERG Remote Control TRC5 key map
- The PrecisionHD camera
- CE Declaration for Codec C90
- China RoHS table
- TANDBERG Codec C90 dimensions
- PrecisionHD 1080p camera dimensions
- PrecisionHD camera dimensions
- Technical specifications
D14129.02—NOVEMBER 2008
18
Codec C90
Administrator Guide
Contents Introduction Getting started About the menus About the settings Settings Library Cameras Appendices Contact us
Admin. Settings menu
Administrator settings, cont...
The Administrator settings menu lets the user:
Open the IP address menu to configure the IP •
settings
Open the • Advanced configuration menu to
access the system configuration settings
The Advanced configuration menu
The Advanced configuration defines the system
settings. The system settings are structured in
a hierarchy, making up a database of system
settings.
!
Changes in the administrator settings may
affect the behavior of the system and should
be configured by the system administrator.
Each setting is explained in the
administrator The settings library section.
In this guide we will concentrate on what’s behind
the Administrator Settings menu and leave the
other menus to be explained in the Codec C90
User Guide.
You can download the Codec C90 User
Guide from our web site.
Go to: http://www.tandberg.com/docs
ADMINISTRATOR SETTINGS
SETTINGS
HOME
Search
Enter the as many characters as needed, until the setting you are
searching for displays in the list.
ADVANCED CONFIGURATIONS
htt
NetworkServices HTTP Mode: On
NetworkServices HTTPS Mode: On
Navigate in the menu
Use the up 1. and down arrow keys on the remote control to navigate in the menu
Press the right 2. arrow key to expand the selected menu item or to move to the
right in a text field
Press the left 3. arrow key to go one step back in the menu or to move to the left in
a text field
Press the OK/Select key to confirm your choice or selection4.
ADVANCED CONFIGURATIONS
ADVANCED CONFIGURATIONS
