Getting started
Turn on the system
Turn on the codec and wait a few minutes for the system to start•
Make sure the remote control has the batteries installed.•
Press • Home ( ) on the remote control to show the menu on screen
When you can see the menu on screen, proceed to Step 2.•
Show the menu:
Press • Home ( ) on the remote control to show the menu on screen
Navigate in the menu:
Use the arrow keys on the remote control to navigate up and down in •
the menus
Confirm your choice:
To confirm your choice, press • OK ( ) on the remote control
1 3
If you need to set a static IP address
Go to IP Settings to set static IP addresses:
Navigate to Settings > Administrator Settings > IP Settings. 1.
Set IP Assignment to Static. Press the left arrow key to go back one step2.
Enter the IP Address, Subnet Mask and Gateway address in the address fields. 3.
The sequence is shown below.
Press 4. OK to save the changes, or Cancel to leave without saving.
Press 5. Home ( ) to exit.
Verify IP address settings
Go to System Information to verify the IP address:
Navigate to Settings > System Information1.
When the IP address is automatically assigned from a DHCP server, the 2.
Address of the codec is shown on the System Information page.
Press 3. Home ( ) to exit.
