4.8.2 Inserting Cartridges into the Magazine
When inserting cartridges the access door of the cartridge must face the magazine.
Push it carefully into the magazine until it locks in place. The rear side of the
cartridge with the Write Protect switch and the barcode label must face out. Make
sure the cartridges latches properly.
Figure 4.17 Gently push the cartridge into the magazine slot
4.8.3 Removing Cartridges from the Magazine
Press the cartridge release tab towards the cartridge until the cartridge is released.
The cartridge is spring loaded so it is important to prevent the cartridge from
popping all the way out. If the cartridge falls down, it may be damaged and data
may be lost. Pull the cartridge carefully out of the magazine slot.
Figure 4.18 Push the release knob
towards the cartridge to eject
Figure 4.19 Cartridge position after
manual release from magazine slot
