Instruction Manual

Figure 12. Wall mounting:
HORIZONTAL
ADJUSTMENT SCREW
(#10-24 x 1-3/8 in.)
METAL WASHER
MOUNTING HUB
MOUNTING HUB
ALIGNMENT
LEDs
STATUS
LEDs
(RECEIVER ONLY)
BEAM LENS
HOLE PLUG
ALIGNMENT ADJUST
POTENTIOMETER
(RECEIVER ONLY)
CABLE EGRESS
HOLE PLUG. USED TO
PLUG UNUSED HOLE.
VERTICAL
ADJUSTMENT
SCREWS (2)
“U” BRACKET
WALL MOUNTING
BRACKET
MOUNTING HOLE
PLASTIC WASHER
C0546-00
Figure 13. Ceiling mounting:
HORIZONTAL
ADJUSTMENT SCREW
(#10-24 x 1-3/8 in.)
METAL WASHER
MOUNTING HUB
MOUNTING HUB
ALIGNMENT
LEDs
STATUS
LEDs
(RECEIVER ONLY)
BEAM LENS
HOLE PLUG
ALIGNMENT ADJUST
POTENTIOMETER
(RECEIVER ONLY)
CABLE EGRESS
HOLE PLUG. USED TO
PLUG UNUSED HOLE.
VERTICAL
ADJUSTMENT
SCREWS (2)
“U” BRACKET
WALL MOUNTING
BRACKET
MOUNTING HOLE
PLASTIC WASHER
C0547-00
D400-18-00 7 I56-494-13R
PRINTED IN MEXICO
