Command Line Interface Reference 8-103
AP51xx>admin(network.wireless.qos)> show
Description:
Displays the access point’s current QoS policy by summary or individual policy.
Syntax:
Example:
admin(network.wireless.qos)>show summary
----------------------------------------------------------------------
QOS Policy Name Associated WLANs
----------------------------------------------------------------------
1 Default 101
2 IP Phones Audio Dept
3 Video Vidio Dept
admin(network.wireless.qos)>show policy 1
Policy Name IP Phones
Support Legacy Voice Mode disable
Multicast (Mask) Address 1 01005E000000
Multicast (Mask) Address 2 09000E000000
WMM QOS Mode disable
For information on configuring the WLAN QoS options available to the access point using the applet (GUI), see
Setting the WLAN Quality of Service (QoS) Policy on page 5-33.
show summary Displays all exisiting QoS policies that have been defined.
policy <index> Displays the configuration for the requested QoS policy.
