AP-51xx Access Point Product Reference Guide8-68
AP51xx>admin(network.wireless.wlan.hotspot.radius)> set
Description:
Sets the Radius hotspot configuration.
Syntax:
Example:
admin(network.wireless.wlan.hotspot.radius)>set server 1 primary 157.235.121.1
admin(network.wireless.wlan.hotspot.radius)>set port 1 primary 1812
admin(network.wireless.wlan.hotspot.radius)>set secret 1 primary sjsharkey
admin(network.wireless.wlan.hotspot.radius)>set acct-mode 1 enable
admin(network.wireless.wlan.hotspot.radius)>set acct-server 1 157.235.14.14
admin(network.wireless.wlan.hotspot.radius)>set acct-port 1 1812
admin(network.wireless.wlan.hotspot.radius)>set acct-secret londonfog
admin(network.wireless.wlan.hotspot.radius)>set acct-timeout 1 25
admin(network.wireless.wlan.hotspot.radius)>set acct-retry 1 10
For information on configuring the Hotspot options available to the access ointusing the applet (GUI), see
Configuring WLAN Hotspot Support on page 5-39.
set server <idx> <srvr_type> <ipadr> Sets the Radius hotpost server IP address per wlan index (1-16)
port <idx> <srvr_type> <port> Sets the Radius hotpost server port per wlan index (1-16)
secret <idx> <srvr_type> <secret> Sets the Radius hotspot server shared secret password.
acct-mode <idx> <mode> Sets the Radius hotspot server accounting mode
(enable/disable)
acct-server <idx> <ipadr> Sets the Radius hotspot accounting server IP address per wlan
index (1-16).
acct-port <idx> <port> Sets the Radius hotspot accounting server port per wlan index
(1-16).
acct-secret <idx> <secret> Sets the Radius hotspot server shared secret password per wlan
index (1-16).
acct-timeout <idx> <timeout> Sets the Radius hotspot server accounting timeout period in
seconds (1-25).
acct-retry <idx>
<retry_count>
Sets the Radius hotspot server accounting accounting retry
interval (1-10).
