AP-51xx Access Point Product Reference Guide8-60
AP51xx>admin(network.wireless.wlan)> create
Description:
Defines the parameters of a new WLAN.
Syntax:
sh
Example:
admin(network.wireless.wlan.create)>show wlan
ESS Identifier :
WLAN Name :
802.11a Radio : available
802.11b/g Radio : not available
Client Bridge Mesh Backhaul : not available
Hotspot : not available
Maximum MUs : 127
Security Policy : Default
MU Access Control :
Kerberos User Name : Default
Kerberos Password : ********
Disallow MU to MU Communication : disable
Use Secure Beacon : disable
create
show wlan <number> Displays newly created WLAN and policy number.
set ess <essid> Defines the ESSID for a target WLAN.
wlan-name
<name> Determines the name of this particlular WLAN (1-32).
11a <mode> Enables or disables access to the access point 802.11a radio.
11bg <mode> Enables or disables access to the access point 802.11b/g radio.
mesh <mode> Enables or disables the Client Bridge Mesh Backhaul option.
hotspot <mode> Enables or disables the Hotspot mode.
max-mu <number> Defines the maximum number of MU able to operate within the WLAN
(default = 127 MUs).
security <name> Sets the security policy to the WLAN (1-32).
acl <name> Sets the MU ACL policy to the WLAN (1-32).
passwd <ascii string> Defines a Kerberos password used if the WLAN’s security policy uses a
Kerberos server-based authentication scheme.
no-mu-mu <mode> Enables or disables MUs associated to the same WLAN to not
communicate with each other.
sbeacon <mode> Enables or disables the AP-51xx from transmitting the ESSID in the
beacon.
bcast <mode> Enables or disables the access point from accepting broadcast IDs from
MUs. Broadcast IDs are transmitted without security.
qos <name> Defines the index name representing the QoS policy used with this
WLAN.
add-wlan Apply the changes to the modified WLAN and exit.
.. Disregard the changes to the modified WLAN and exit.
