AP-51xx Access Point Product Reference Guide8-50
AP51xx>admin(network.wan.vpn)> set
Description:
Sets VPN entry parameters.
Syntax:
set type <name> <tunnel type> Sets the tunnel type <name> to Auto or Manual
for the specified tunnel name.
authalgo <name> <authalgo> Sets the authentication algorithm for <name> to
(None, MD5, or SHA1).
authkey <name> <dir> <authkey> Sets the AH authentication key (if type is
Manual) for tunnel <name> with the direction set
to IN or OUT, and the manual authentication key
set to <authkey>. (The key size is 32 hex characters
for MD5, and 40 hex characters for SHA1).
esp-type <name> <esptype> Sets the Encapsulating Security Payload (ESP)
type. Options include None, ESP, or ESP-AUTH.
esp-encalgo <name> <escalgo> Sets the ESP encryption algorithm. Options include
DES, 3DES, AES128, AES192, or AES256).
esp-enckey <name> <dir> <enckey> Sets the Manual Encryption Key in ASCII for tunnel
<name> and direction IN or OUT to the key <enc-
key>. The size of the key depends on the
encryption algorithm.
- 16 hex characters for DES
- 48 hex characters for 3DES
- 32 hex characters for AES128
- 48 hex characters for AES192
- 64 hex characters for AES256
esp-authalgo <name> <authalgo> Sets the ESP authentication algorithm. Options
include MD5 or SHA1.
esp-authkey <name> <dir> <authkey> Sets ESP Authentication key <name> either for IN
or OUT direction to <auth-key>, an ASCII string of
hex characters. If authalgo is set to MD5, then
provide 32 hex characters. If authalgo is set to
SHA1, provide 40 hex characters.
spi <name> <algo> <dir> <value> Sets 6 character IN(bound) or OUT(bound) for
AUTH (Manual Authentication) or ESP for
<name> to <spi> (a hex value more than 0xFF)
<value>.
usepfs <name> <mode> Enables or disables Perfect Forward Secrecy for
<name>.
