Command Line Interface Reference 8-41
AP51xx>admin(network.wan)> set
Description:
Defines the configuration of the access point WAN port.
Syntax:
Example:
admin(network.wan)>
admin(network.wan)>set dhcp disable
admin(network.wan)>set ipadr 157.169.22.5
admin(network.wan)>set dgw 157.169.22.1
admin(network.wan)>set dns 1 157.169.22.2
admin(network.wan)>set mask 255.255.255.000
admin(network.wan)>set pppoe mode enable
admin(network.wan)>set pppoe type chap
admin(network.wan)>set pppoe user jk
admin(network.wan)>set pppoe passwd @#$goodpassword%$#
admin(network.wan)>set pppoe ka enable
admin(network.wan)>set pppoe idle 600
For an overview of the WAN configuration options available using the applet (GUI), see Configuring WAN Settings on page 5-14.
set wan enable/disable Enables or disables the access point WAN port.
dhcp enable/disable Enables or disables WAN DHCP Client mode.
ipadr <idx> <a.b.c.d> Sets up to 8 (using <indx> from 1 to 8) IP addresses <a.b.c.d> for the
access point WAN interface.
mask <a.b.c.d> Sets the subnet mask for the access point WAN interface.
dgw <a.b.c.d> Sets the default gateway IP address to <a.b.c.d>.
dns <idx> <a.b.c.d> Sets the IP address of one or two DNS servers, where <indx> indicates
either the primary (1) or secondary (2) server, and <a.b.c.d> is the IP
address of the server.
pppoe mode enable/disable Enables or disables PPPoE.
user <name> Sets PPPoE user name.
passwd <password> Defines the PPPoE password.
ka enable/disable Enables or disables PPPoE keepalive.
idle <time> Sets PPPoE idle time.
type <auth-type> Sets PPPoE authentication type.
