Usage Scenarios
B-13
B.2.3 Frequently Asked VPN Questions
The following are common questions that arise when configuring a VPN tunnel using the access
point.
• Question 1: Does the access point IPSec tunnel support multiple subnets on the
other end of a VPN concentrator?
Yes. The access point can access multiple subnets on the other end of the VPN Concentrator
from the access point's Local LAN Subnet by:
• Creating multiple VPN Tunnels. The AP supports a maximum of 25 tunnels.
• When using the Remote Subnet IP Address with an appropriate subnet mask, the AP can
access multiple subnets on the remote end.
For example: If creating a tunnel using 192.168.0.0/16 for the Remote Subnet IP address, the
following subnets could be accessed:
192.168.1.x
192.168.2.x
192.168.3.x, etc
