Technical Specifications
A-3
A.1.2 AP-5181 Physical Characteristics
The AP-5181 has the following physical characteristics:
Dimensions TBD
Housing TBD
Weight TBD
Operating
Temperature
30 to 55° Celsius
Storage Temperature 40 to 85° Celsius
Altitude 8,000 feet/2438 m @ 28° Celsius (operating)
15,000 feet/4572 m @ 12° Celsius (storage)
Vibration Vibration to withstand .02g²/Hz, random, sine, 20-2k Hz
Humidity 5 to 95% (operating) 5 to 95% (storage)
Electrostatic
Discharge
15kV (air) @ 50% rh
8kV (contact) @ 50% rh
Drop Bench drop 36 inches to concrete
Wind Blown Rain 40 MPH @ 0.1inch/minute, 15 minutes
Rain/Drip/Spill IPX5 Spray @ 4L/minute, 10 minutes
Dust IP6X 20mb vacuum max, 2 hours, stirred dust,
.88g/m^3 concentration @ 35%RH
