Configuring Mesh Networking
9-27
26. The team decides to leave the Disallow MU to MU Communication checkbox unselected
for the WLAN, as the team considers all MU traffic within the secure shipping and receiving
yard known and not a threat to the initial 2 AP mesh network deployment.
27. The team selects the Use Secure Beacon checkbox from the Edit WLAN screen to not
transmit the AP- 5131’s ESSID between AP1 and AP2. If a hacker tries to find an ESSID via
an MU, the AP- 5131’s ESSID does not display since the ESSID is not in the beacon.
28. The team does not select the Accept Broadcast ESSID checkbox from the Edit WLAN
screen to associate MUs with a blank ESSID, as they do not want MUs randomly joining
their carefully constructed mesh network.
29. From the Edit WLAN screen, the IT Team selects the Create button to the right of the Quality
Of Service Policy drop-down menu.
The New QoS Policy screen displays with no values selected.
30. The IT Team assigns the name of “mesh network qos” to the QoS policy to eliminate any
confusion with the policy’s intended function.
