AP-51xx Access Point Product Reference Guide
9-22
default of 15 seconds. Since only one additional access point is to be added to this point-to-
point mesh network, the Forwarding Table Ageout value is also unchanged from its 100
second default setting.
8. The team clicks OK from within the Bridge STP Configuration screen and Apply from within
the trion (LAN1) screen to save the settings. This step is repeated for AP2.
The Trion IT team now intends to create a WLAN (to use with the trion LAN) that can be
dedicated to their mesh network within the shipping yard.
9. Select Network Configuration -> Wireless from the AP-5131 menu tree.
The Wireless Configuration screen displays with those existing WLANs displayed within
the table. This is Trion’s first deployment for this new dual-radio access point, upon
reviewing the Wireless Page they determine the existing default WLAN should be left as is
and a new WLAN should be created that can be dedicated to the mesh network supporting
the shipping yard.
