Command Line Interface Reference 8-187
AP51xx>admin(stats)> show
Description:
Displays access point system information.
Syntax:
For information on displaying WAN port statistics using the applet (GUI), see Viewing WAN Statistics on page 7-2.
For information on displaying LAN port statistics using the applet (GUI), see Viewing LAN Statistics on page 7-6.
For information on displaying Wireless statistics using the applet (GUI), see Viewing Wireless Statistics on page 7-11.
For information on displaying individual WLAN statistics using the applet (GUI), see Viewing WLAN Statistics on page 7-13.
For information on displaying Radio statistics using the applet (GUI), see Viewing Radio Statistics Summary on page 7-17.
For information on displaying MU statistics using the applet (GUI), see Viewing MU Statistics Summary on page 7-23.
For information on displaying Mesh statistics using the applet (GUI), see Viewing the Mesh Statistics Summary on page 7-29.
For information on displaying Known AP statistics using the applet (GUI), see Viewing Known Access Point Statistics on page 7-30.
show wan Displays stats for the access point WAN port.
lan Displays stats for the access point LAN port
stp Displays LAN Spanning Tree Status
wlan Displays WLAN status and statistics summary.
s-wlan Displays status and statistics for an individual WLAN
radio Displays a radio statistics transmit and receive summary.
s-radio Displays radio statistics for a single radio
retry-hgram Displays a radio’s retry histogram statistics.
mu Displays all mobile unit (MU) status.
s-mu Displays status and statistics for an individual MU.
auth-mu Displays single MU Authentication statistics.
wlap Displays Wireless Bridge Statistics statistics summary.
s-wlap Displays single Wirless Bridge statistics.
known-ap Displays a Known AP summary.
