Installation Guide
DROP-IN BATHTUB INSTALLATION INSTRUCTIONS
WARNING: All plumbing installations must be done in accordance
to legal regulations.
ATTENTION! Before installing the bathtub:
• Make sure all wood studs and supports are properly installed.
• Verify all the necessary plumbing is installed by a certied plumber.
• Floor drain and trap are not included. Make sure to install according to
local and legal regulations.
1. Read the complete instruction manual before beginning installation.
2. Conrm that your model will t in intended location and plumbing xtures are
located where legally required before beginning installation.
3. Not all drawings on this manual are drawn to scale. Please refer to the model chart.
4. Walls and sub-oor must be solid, and square.
5. Always use drop cloth to protect bathtub from damage during installation.
6. Two people must be used at all times to move and install bathtub.
— 6 —
* Rough plumbing must be installed before bathtub installation.
* Floor drain and trap are not included. Make sure to install according to local and legal regulations.
1. Roughing-in Drain and Bathtub
