Installation Instructions
Corner Soap Dish Installation
The soap dish is a corner mount design. The soap dishes can
be stacked in one corner or placed in opposite corners.
Note:
The soap dish is molded with a square corner,
as shown in the illustrations.
1. Select a desirable height for mounting one or both soap
dishes.
2. After marking the height, draw a 4 inch level line on both
walls. These lines will be used to align the top edges of
the soap dish.
3. Dry t the soap dish prior to applying clear silicone. The
soap dish may require sanding to t precisely in the corner.
The actual angle of the soap dish is slightly greater than 90
degrees to accommodate some adjustment. If necessary,
mark and sand the side(s) of the soap dish to achieve a
proper t, using a coarse grit (60 grit) sandpaper.
4. Apply silicone to the edge of the soap dish.
Note: Either clear or color matched silicone can be
used for attaching the soap dish.
5. Align the soap dish with the level lines and press it into
place.
6. Hold the soap dish securely in place and wipe off excess
silicone. You will want a uniform bead on both top and
bottom.
7. Temporarily secure the soap dish with masking tape, as
shown. Remove the tape after approximately two hours. Do
not place anything on the soap dish for at least 24 hours.
Corner Molding (if applicable)
Installing the corner molding is optional. If the panels were
scribed and cut to create a tight-tting corner, then the corner
molding can be eliminated. If, however, there are gaps between
the side and rear panels, the corner molding should be
installed. Either option, if done properly, is acceptable.
If the optional soap dish was installed, cut one piece of the
molding to t above the soap dish and one for below the soap
dish.
Note: Either clear or color matched silicone can be used to
install corner molding strips. If the kit is supplied
with corner moldings, it will contain enough silicon
(clear or color matched) to install the corner molding
strips.
1. Measure and cut the corner moldings to length.
Swan 14 800-325-7008
Installation Procedure
