Installation Instructions

b. If the uncovered area of the back wall is less than
the width of the next panel, cut the panel to fit the
opening. It is not necessary for the seam in the
back panels to be centered, as it will be covered.
c. If a gap exists between the two back wall panels,
install a foam spacer (provided) between the two
panels and 1/4 inch from the upper edge. This
foam spacer will help fill the gap when caulking the
panel. Apply sealant to the back of the center
panel, keeping the sealant at least one inch from
the panel edges.
5. Firmly press the surface of each panel against the wall. It is
important to apply hand pressure to the entire surface of the
panel to bond it to the wall surface.
DO NOT force a panel to t a bowed or curved wall as it may
break; furthermore, the resiliency of the panel can break the
silicone bond to the wall surface.
Apron Strips (optional)
If the wall and/or wall panel extends beyond the edge of the
bathtub, adding apron strips will provide a nished look to the
installation.
Two small apron strips come with the SSIT-60-3 kit or they
can be cut from scraps of a panel when using other kits. When
cutting these apron strips, make sure the nished edge of the
panel is facing outward. Trial t the apron strips before nal
installation.
1. If using the apron strips from the kit, proceed to the next
step.
If making the apron strip from the excess of a panel,
measure the distance from the edge of the bathtub to the
outside of the wall panel. Cut two pieces of the Swanstone
material at least 1/2 inch larger than the measured distance
to t in this area.
2. Hold the apron strips in place and scribe the angle of the
bathtub base onto each piece. Remember, do not cut the
nished edge.
Fumes Hazard
The fumes from the silicone sealant and solvents
used by the installer can be harmful if used in
an unventilated room. Always work in a well-ventilated area. To
keep the area well-ventilated, open windows and use exhaust
fans. If adequate ventilation is not achievable or practical, use
respiratory protective equipment.
3. Clean the back of the apron strip with denatured alcohol.
Do not use oil-based cleaners, such as mineral spirits, to clean
the panels. The oil in the cleaner will prevent the panel from
properly adhering to the wall.
4. Place silicone on the back side of the apron strips.
5. Attach the apron strips to the wall.
Note: Make sure the top edges of both apron strips
are against the bottom lip of the side panels.
IMPORTANT NOTICE
WARNING
IMPORTANT NOTICE
800-325-7008 13 Swan
Installation Procedure
