Dimensions Guide

TECHNICAL SPECIFICATIONS
A
2
COMPOSITE
www.a2bath.com
48"
16 1/2"
34"
24"
6"
A
DETAIL A:
Locking slots for
optional walls
A
A
A
4834CPAN
48 x 34 x 6
inches
FEATURES Dimensional Tolerance ±
3
⁄8”.Dimensions needed for site preparation should be measured from the unit.Manufacturer assumes no responsibility for preparatory work.
Model # Material Drain
Net Wt.
lbs
Pkg. Wt.
lbs
Shower Pan #4834CPAN A
2
Composite Center 36 41
DIMENSIONS
Specifications
inches
Width: Overall / Net
48
Depth: Overall / Net 34
Height: Overall / Net 7 / 6
Enclosure Opening –
Skirt Height 6
Drain Rough-In (from Back Wall) 16
1
⁄2
Drain Rough-In (from Side Wall) 24
Drain: Diameter / Clearance 3
1
⁄4 /
3
⁄8
FRAMING DIMENSIONS inches
Type
D
Depth
W
Width
H
Height
A B C
Alcove
34 48
– Box Out 24 16
1
⁄2
D
W
C
B
A
6"
76"
48"
44
1
/
8
"
34"
22"
26"
18"
Shelf Space
Top: 4" x 6 ½"
Mid: 4" x 7 ¾"
Bottom: 4" x 10 ¼"
7
15
/
16
"
Rev. 01.28.19
