Note: The term “IC” before the radio certication number only signies that Industry Canada technical specications were met.
Troubleshooting & Specications
Kitting
TROUBLESHOOTING
If you have any questions during setup, please reach out to our US-based experienced support technicians:
Call: 1-888-365-6283
Email: [e-mail]
Visit: www.surecall.com/support
Problem Resolution
Signal booster has
no power
Connect the power supply to an alternate power source.
Verify that the power source is not controlled by a switch that has removed power from the outlet.
If it remains OFF, contact tech support at: 1-888-365-6283 or [e-mail]
After completing
installation, indoor
signal coverage has
not improved
Verify that cable connections are tightly tted to the booster and antenna.
Try further separating the booster and antenna.
Verify that there is usable signal where the antenna is placed.
Note: Bars are not always a reliable measure of signal. The best way to conrm signal coverage is
the ability to place and hold a call.
SPECIFICATIONS
Model Fusion4Home 3.0 (US), Fusion4Home 3.0 CA (Canada)
Uplink Frequency Range (MHz): 698-716 / 776 – 787 / 824-849 / 1850-1915 / 1710-1755
Downlink Frequency Range (MHz): 728-746 / 746 – 757 / 869-894 / 1930-1995 / 2110-2155
Maximum Gain: 72 dB
Supported Standards: CDMA, WCDMA, GSM, EDGE, HSPA+, EVDO, LTE and all cellular standards
Max Uplink Power: 26.0 dBm
Input Impedance: 75Ω donor port / 50Ω server port
Noise Figure: 8 dB
AC Input: Input AC110V, 60 Hz; Output DC 5-15V
Maximum Output Power: 1 Watt EIRP
Cable: RG6 / SC-240
RF Connectors: F Female (outdoor) / N Female (indoor)
Power Consumption: <15W
Operation Temperature: -4º to +158º F
Dimensions: 7.875 x 5 x 1.188 inches
Weight: 2 LB 3 oz
Certications: FCC ID: RSNF4HOME (US), IC: 7784A-F4HOME (Canada)
Kitting
Component Product number Gain/Loss Note
LTE-A
707 MHz
LTE-V
731 MHz
Cellular
800 MHz
PCS
1900 MHz
AWS
1700 / 2100 MHz
Outdoor
Antenna*
SC-289W-75Ω
3 dBi 3 dBi 3 dBi 4 dBi 4 dBi / 4 dBi
SC-231W-75Ω
7 dBi 7 dBi 8 dBi 10 dBi
10 dBi / 10 dBi
Outdoor Cable* RG6 - 50 (50’)
3.32 dB 3.32 dB 3.75 dB 6.42 dB
6.22 dB / 6.68 dB
50 Feet or longer
Inside Cable* SC-240-20NN (20’)
2.06 dB 2.06 dB 2.29 dB 3.56 dB 3.36 dB / 3.76 dB 20 Feet or longer
Inside Antenna* SC-248W
7 dBi 7 dBi 7 dBi 10 dBi 10 dBi / 10 dBi
SC-222W
3 dBi 3 dBi 3 dBi 6 dBi 6 dBi / 6 dBi
SC-121W
1.2 dBi 1.2 dBi 1.2 dBi 3 dBi 3 dBi / 3 dBi
SC-302W
2.5 dBi 2.5 dBi 3 dBi 5 dBi 4 dBi / 5 dBi
* All equivalent antennas and cables are suitable for use with the Fusion4Home 3.0
PreAGC
Pulse GSM 4.1 MHz AWGN Limit
Frequency Input Output Gain Input Output Gain Gain
(MHz) (dBm) (dBm) (dB) (dBm) (dBm) (dB) (dB)
Uplink: 1710-1755 -48.9 20.8 69.7 -48.2 21.6 69.8 71.3
Uplink: 1850-1915 -50.3 20.4 70.7 -47.6 20.6 68.2 72.0
Uplink: 824-849 -34.9 25.1 60.0 -35.5 24.1 59.6 64.9
Uplink: 698-716 -33.6 25.7 59.3 -36.2 24.4 60.6 63.5
Uplink: 777-787 -31.8 26.0 57.8 -35.8 25.4 61.2 64.4
Downlink: 2110-2155 -61.4 9.2 70.6 -60.6 9.1 69.7 N/A
Downlink: 1930-1995 -59.2 7.9 67.1 -58.0 8.5 66.5 N/A
Downlink: 869-894 -56.0 8.2 64.2 -56.5 6.4 62.9 N/A
Downlink: 728-746 -54.8 6.2 61.0 -57.3 3.7 61.0 N/A
Downlink: 746-757 -53.8 8.0 61.8 -54.7 6.4 61.1 N/A
Warning: Any product modications that use unauthorized antennas, cables, and/or coupling devices are prohibited by the FCC. Contact FCC for details:
1-888-CALL-FCC. Changes or modications not expressly approved by SureCall could void the user’s authority to operate the equipment.
