X9DRW-7TPF+/iTPF+ Motherboard User’s Manual
Warning: To avoid damaging the power supply or motherboard, please use a power
supply that contains a 24-pin and two 8-pin power connectors. Be sure to connect these
power connectors to the 24-pin power connector located at JPW1 and the two 8-pin
power connectors located at JPW2/JPW3 on the motherboard. Failure in doing so will
void the manufacturer warranty on your power supply and motherboard.
SAS 0~3, 4~7 SAS Connectors from LSI 2208 SAS Controller
SP1 Onboard Buzzer (Internal Speaker)
SXB1A/1B/1C CPU1 Slot2 PCI-E 3.0 x 16 +16 SMCI-Proprietary (Left) Add-
On Slot
SXB2 CPU2 Slot1 PCI-E 3.0 x 16 (Right) Add-On Slot
T-SGPIO 1/2 Serial-Link General_Purpose IO Headers for I-SATA 0~5
USB 0/1 Back Panel USB 0/1
USB 2/3, 4/5 Front Panel Accessible USB 2/3, 4/5 Connections
USB 6 Front Panel Type A USB 6 Port
UID Switch UID (Unit Identier) Switch
VGA1 Backpanel VGA Port
X9DRW-7TPF+ LED Indicators
LED Description Color/State Status
LE1 Power LED Green: On SB Power On
LE2 UID LED Blue Unit Identied
LED1
10G (T)LAN Ports 3/4
LED Indicators
Green Normal
LEDS1 SAS Activity LED Green: SAS Active SAS Active
LEDS2 SAS Fault LED On SAS Error(s)
LEM2 BMC Heartbeat LED Green BMC Normal
