Power LED/Speaker
On the JDI header, pins 1-3 are
for a power LED and pins 4-7 are
for the speaker. See the table on
the right for speaker pin defini-
tions. Note: The speaker connec-
tor pins are for use with an exter-
nal speaker. If you wish to use
the onboard speaker, you should
close pins 6-7 with a jumper.
Speaker Connector Pin
Definitions (JD1)
Pin
Number
4
5
6
7
Function
+
Key
Definition
Red wire, Speaker data
No connection
Key
Speaker data
Fan Headers
The X6DHT-G has eight fan head-
ers (Fan1 to Fan8). (*Note: Fans
5-8 are 4-pin fans. However, Pins
1-3 of the fan headers are back-
ward compatible with the tradi-
tional 3-pin fans.) See the table on
the right for pin definitions. (*The
onboard fan speed is controlled by
Thermal Management via BIOS--
Hardware Monitor in the Ad-
vanced Setting. Note: Default: Dis-
abled, When using Thermal Man-
agement setting, please use all 3-
pin fans or all 4-pin fans on the
motherboard. Please do not use 3-
pin fans and 4-pin fans on the
same board.)
4-pin Fan Header Pin Definitions
Pin#
1
2
3
Definition
Ground (black)
+12V (red)
Tachometer
Caution: These fan headers use DC power.
4
PWM_Control
PWR LED/SPKR
Fan 7
Fan 5
Fan 6
Fan 1
Fan 2
Fan 3
Fan4
Fan8
