▪ 6-Axis arm
o Removable arm for improved versatility
o Vertical reach: 61 inches. Horizontal reach: 48”
o Arm payload: 15 lbs. fully extended
o Base rotation: 400 degrees
o Shoulder rotation: 190 degrees
o Elbow rotation: 270 degrees
o Wrist: continuous rotation and +/- 90 degrees tilt (180 total)
o Parallel Finger Gripper: 4.5” opening with 65lb squeeze force
▪ Camera system
o Primary 30X zoom tilt camera embedded in the nose of the robot with high intensity LED light
o Gripper IR camera
o Rear view/backup IR camera.
o Removable rear mounted perspective PTZ camera with 30x optical zoom, CREE LED spotlight,
and tactical laser pointer.
▪ Operator Control Unit (OCU)
o Rugged Pelican case style enclosure with Microsoft Surface Pro 12” touch screen tablet
o 2.4GHz high power digital radios
o Lithium-ion battery, 11.1V 10Ah
o Integrated joysticks to intuitively control drive, cameras, flipper arms, and manipulator
o Two modes of control (cartesian and joint) for easy manipulator control with preset positions
o Preset positions for flipper/stabilizer arms for stowing and climbing stairs
o 2-way audio
o Quad view camera display (switch between cameras, split screen, or all cameras in quad view)
o Advanced kinematic modeling and collision detection – see a 3D model of the robot with the
current position of the arm and flipper arms with collision warnings.
o Video recording and image snapshots
▪ Battery Charging - The smart chargers are fully automatic and will charge all the batteries
simultaneously with a single 115VAC plug (230 VAC also available upon request).
▪ NIST Qualified Design – Outperformed competition at National Institute of Standards and
Technology event
▪ EOD Ready – Mounting for Carbon Fire 10 Disruptor included.
▪ Ethernet Jacks – Ethernet jacks are included in OCU and Robot for connection of 4G routers or
ethernet tether.
▪ Store and protect – Reusable foam lined transport case
▪ Unlimited Technical Support
▪ Training Video and PDF Operation Manual
