User's Manual

C-10

uperWorkstation 7045A-C3/7045A-CT User's Manual

C-2 Installing Windows XP/2000/2003 for RAID Systems

Installing a New Operating System-the Windows XP/2000/2003 OS

a. Insert Microsoft's Windows XP/2000/2003 Setup CD in the CD Driver, and the

system will start booting up from CD.

b. Press the <F6> key when the message-" Press F6 if you need to install a third

party SCSI or RAID driver" displays.

c. When the Windows XP/2000/2003 Setup screen appears, press "S" to specify

additional device(s).

d. Insert the driver diskette-"Intel AA RAID XP/2000/2003 Driver for ICH9R into

Drive A: and press the <Enter> key.

e. Select the Intel(R)82801GR/GH SATA RAID Controller from the list indicated

in the XP/2000/2003 Setup Screen, and press the <Enter> key.

f. Press the <Enter> key to continue the installation process. (If you need to

specify any additional devices to be installed, do it at this time.) Once all devices

are speciﬁ ed, press the <Enter> key to continue with the installation.

g. From the Windows XP/2000/2003 Setup screen, press the <Enter> key. The

XP/2000/2003 Setup will automatically load all device ﬁ les and then, continue the

Windows XP/2000/2003 installation.

h. After the Windows XP/2000/2003 Installation is completed, the system will

automatically reboot.

i. Insert the Supermicro Setup CD that came with the package into the CD Drive

during system reboot, and the main screen will appear.

Note: the current version of the ICH9R SATA RAID Utility can only support the

Windows XP/2000/2003 Operating System.
